2002 Arctic Cat SBS 1000 — FRONT TIRE AND STEERING ASSEMBLY
2002 SBS 1000
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3401-406 | TIRE | 1 | $114.95 | |
| 2 | 3401-383 | WHEEL-W/BEARINGS | 1 | $139.95 | |
| 3 | 3401-384 | SPACER | 1 | $16.95 | |
| 4 | 3401-385 | BEARING-BALL | 1 | $57.95 | |
| 5 | 3401-386 | STEM-VALVE | 1 | $11.95 | |
| 6 | 3401-131 | NUT-LOCK, NI(.500-13,STL,YZ,LI | 1 | $11.95 | |
| 7 | 3401-390 | WASHER-THRUST | 1 | $11.95 | |
| 8 | 3401-391 | SPINDLE-RH | 1 | $236.95 | |
| 9 | 3401-392 | RH BALL JOINT | 1 | $45.95 | |
| 10 | 3401-393 | NUT | 1 | $1.95 | |
| 11 | 3401-394 | LH BALL JOINT | 1 | $45.95 | |
| 12 | 3401-396 | ROD-TIE | 1 | $35.95 | |
| 13 | 3401-397 | NUT-JAM | 1 | $6.95 | |
| 14 | 3401-398 | NUT-JAM | 1 | $14.95 | |
| 15 | 3401-399 | SLEEVE-KINGPIN | 1 | $20.95 | |
| 16 | 3401-067 | FITTING-LUBE | 1 | $4.95 | |
| 17 | 3401-066 | "FITTING-GREASE (1/4-28X.55,TAP" | 1 | $4.95 | |
| 18 | 3401-400 | SCREW-HH | 1 | $25.95 | |
| 19 | 3401-401 | SPINDLE-LH | 1 | $236.95 | |
| 20 | 3401-402 | PIN-COTTER | 1 | $0.75 | |
| 21 | 3401-230 | WASHER-FLAT | 1 | $11.95 | |
| 22 | 3401-387 | WASHER | 1 | $6.95 | |
| 23 | 3401-388 | SCREW-HH | 1 | $8.95 | |
| 24 | 3401-389 | CAP-DUST | 1 | $3.95 |
