UPPER STEERING ASSEMBLY
2002 SBS 1000
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3401-122 | "NUT-HEX (M12-1.25,PC5,YZ)" | 1 | $14.95 | |
| 2 | 3401-148 | WASHER-LOCK | 1 | $1.95 | |
| 3 | 3401-168 | "WHEEL-STEERING (14"")" | 1 | $56.95 | |
| 5 | 3401-229 | STEERING GEARBOX ASM | 1 | $410.95 | |
| 6 | 3401-147 | SCREW-HH (M8 X30) | 1 | $6.95 | |
| 7 | 3401-105 | "WASHER-LOCK (SP .313,STL,YZ,.1" | 1 | $1.95 | |
| 8 | 3401-227 | SHAFT-STEERING | 1 | $152.95 | |
| 9 | 3401-088 | "SCREW-HH(.312-18X2.000,GR5,YZ)" | 1 | $4.95 | |
| 10 | 3401-159 | "BUSHING-UPPER, STEERING" | 1 | $16.95 | |
| 11 | 3401-091 | "SCREW-CARR (.312-18 X .750, GR" | 1 | $2.95 | |
| 12 | 3401-224 | SPINDLE-RH (CASTING-BLACK) | 1 | $113.95 | |
| 13 | 3401-051 | COVER-DUST | 1 | $17.95 | |
| 14 | 3401-048 | "NUT-FLANGE, NI (5/16-18 UNC)" | 1 | $1.95 | |
| 15 | 3401-036 | "DECAL-STEERING WHEEL, AC" | 1 | $9.95 | |
| 16 | 3401-001 | COLLAR | 1 | $6.95 | |
| 17 | 3401-492 | SCREW-HS | 1 | $8.95 |
