FRONT BRAKE ASSEMBLY
2004 400 DVX
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3406-023 | CALIPER ASSY,FRONT | 1 | $365.95 | |
| 1 | 3406-030 | CALIPER ASSY,FRONT | 1 | $350.95 | |
| 2 | 3406-021 | PISTON SET | 1 | $62.95 | |
| 4 | 3406-036 | SPRING,PAD | 1 | $20.63 | |
| 5 | 3406-043 | BOOT | 1 | $20.95 | |
| 6 | 3423-584 | BOLT,PIN | 1 | $12.35 | |
| 7 | 3406-035 | WASHER,WAVE | 1 | $1.78 | |
| 8 | 3406-024 | PIN,SLIDE | 1 | $37.95 | |
| 9 | 3406-034 | WASHER,FRICTION | 1 | $3.02 | |
| 10 | 3406-042 | DUST SEAL | 1 | $12.35 | |
| 11 | 3406-033 | BOOT,PIN | 1 | $17.87 | |
| 12 | 3406-037 | PIN,HOLDER | 1 | $33.95 | |
| 13 | 3406-027 | BRACKET,R | 1 | $78.95 | |
| 13 | 3406-040 | BRACKET,L | 1 | $90.95 | |
| 14 | 3406-025 | BLEEDER | 1 | $20.63 | |
| 15 | 3406-026 | CAP,BLEEDER | 1 | $12.95 | |
| 16 | 3406-031 | PAD & SHIM SET,R | 1 | $122.95 | |
| 16 | 3406-032 | PAD & SHIM SET,L | 1 | $122.95 | |
| 17 | 3406-041 | SHIM | 1 | $20.63 | |
| 17 | 3406-082 | SHIM | 1 | $20.63 | |
| 18 | 3423-612 | BOLT (8X16) | 1 | $3.02 |
