GEAR SHIFTING ASSEMBLY
2006 500 AUTOMATIC TRANSMISSION 4X4 TRV
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3423-418 | BOLT, BASE ASSY | 1 | $3.30 | |
| 2 | 3530-042 | BASE ASSY,GEAR SHIFT TERM | 1 | $196.95 | |
| 3 | 3423-044 | PIN,CAM GEAR,5MM | 1 | $5.37 | |
| 4 | 3402-087 | SPRING,COMPRESSION,M4 | 1 | $3.30 | |
| 5 | 3423-421 | WASHER, SHIFT SHAFT (M25X34X1.0) | 1 | $5.51 | |
| 6 | 3423-191 | CIRCLIP,FASTENER | 1 | $2.33 | |
| 7 | 3402-826 | SHAFT, GEAR SHIFT | 1 | $163.95 | |
| 8 | 3423-114 | MM (DOWEL) | 1 | $2.06 | |
| 9 | 3402-382 | SHIM,M25X32X1 | 1 | $6.34 | |
| 10 | 3446-280 | SPRING, SUB T/M SHIFT CAM | 1 | $10.95 | |
| 11 | 3402-827 | CAM, GEAR SHIFT REVERSE | 1 | $112.95 | |
| 12 | 3423-871 | CIRCLIP | 1 | $3.71 | |
| 13 | 3446-353 | FORK, SUB T/M GEAR SHIFT | 1 | $122.95 | |
| 14 | 3402-828 | CAM, GEAR SHIFT | 1 | $133.95 | |
| 15 | 3402-381 | WASHER,M20X34X1 | 1 | $3.57 | |
| 16 | 3423-446 | SHIM, (0.5) | 1 | $6.34 | |
| 17 | 3402-642 | PLATE, GR SHIFT CAM STOPPER | 1 | $97.95 | |
| 18 | 3007-380 | BOLT | 1 | $3.16 | |
| 19 | 3423-876 | CIRCLIP,REV SHIFT CAM FASTENER | 1 | $3.44 | |
| 20 | 3402-747 | SHAFT, SUB T/M GEAR | 1 | $114.95 | |
| 21 | 1691-043 | SHIM, M12X20X1.0 | 1 | $3.44 | |
| 22 | 3402-076 | OIL SEAL,M12X22X9 | 1 | $16.49 | |
| 23 | 3402-434 | ARM, COMPRESSION,-SELECT | 1 | $79.95 | |
| 24 | 3007-409 | BOLT | 1 | $3.16 | |
| 25 | 3423-141 | WASHER, GEAR SHIFT CAM STOPPER-M6X14 | 1 | $3.95 | |
| 26 | 3402-746 | STOPPER, SHIFT CAM | 1 | $26.95 | |
| 27 | 3446-048 | SUPPORT, CAM STOPPER ARM | 1 | $32.95 | |
| 28 | 3423-511 | SPRING, SHIFT CAM STOPPER | 1 | $12.35 | |
| 29 | 3423-438 | WASHER, 6.5 X 16 X 2.3 | 1 | $2.95 | |
| 30 | 3007-373 | NUT | 1 | $3.16 | |
| 31 | 3446-266 | SHAFT, GEAR SHIFT FORK | 1 | $47.95 | |
| 32 | 3402-829 | BEARING | 1 | $45.95 |
