THROTTLE CASE AND CONTROL SWITCH ASSEMBLIES
2006 650 V-TWIN AUTOMATIC TRANSMISSION 4X4 FIS CA
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0509-012 | THROTTLE, SELECTOR - ASSEMBLY (2WD/4WD) | 1 | $199.95 | |
| 2 | 0409-048 | SWITCH, ACTUATOR (2WD/4WD) | 1 | $112.95 | |
| 3 | 3007-392 | BOLT | 1 | $3.95 | |
| 4 | 3004-447 | WASHER, LOCK 6MM | 1 | $3.16 | |
| 5 | 3003-030 | WASHER, FLAT | 1 | $2.75 | |
| 6 | 3423-327 | NUT,5MM | 1 | $2.33 | |
| 7 | 3423-014 | SCREW,5MM | 1 | $2.06 | |
| 8 | 3409-001 | LEVER,THROTTLE | 1 | $26.95 | |
| 9 | 3423-199 | SCREW, 5X30 | 1 | $1.78 | |
| 10 | 0487-032 | CABLE,THROTTLE | 1 | $160.95 | |
| 11 | 0409-022 | SWITCH, CONTROL LH - ASSEMBLY (W/ OVER R | 1 | $196.95 | |
| 12 | 0409-026 | COVER, CHOKE LEVER | 1 | $17.87 | |
| 13 | 0409-025 | LEVER, CHOKE | 1 | $20.63 | |
| 14 | 0409-028 | SCREW, SWITCH CONTROL - 5X45-6ZK | 1 | $4.95 | |
| 15 | 0409-027 | SCREW, SWITCH CONTROL - 5X35-6ZK | 1 | $4.95 | |
| 16 | 0487-033 | CABLE,CHOKE | 1 | $113.95 |
