2008 Arctic Cat 250 DVX — PILOT LAMP ASSEMBLY
2008 250 DVX
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3304-285 | PILOT LAMP COMP | 1 | $84.95 | |
| 2 | 3304-284 | BULB WEDGE BASE T5 | 1 | $2.75 | |
| 3 | 3304-650 | SCREW TAPPING 5*16 (CIRCLE HEAD) | 1 | $1.50 |
