2008 Arctic Cat PROWLER XTX 700 H1 AUTOMATIC 4X4 — SWAY BAR ASSEMBLY
2008 PROWLER XTX 700 H1 AUTOMATIC 4X4
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0404-110 | SWAYBAR,REAR (3/4IN)-BLACK | 1 | $129.95 | |
| 2 | 0404-135 | CLAMP,SWAYBAR BUSHING-BLACK | 1 | $19.25 | |
| 3 | 0404-094 | BUSHING,UPPER HALF-SWAYBAR | 1 | $5.92 | |
| 4 | 0404-095 | BUSHING,LOWER HALF-SWAYBAR | 1 | $5.92 | |
| 5 | 8409-016 | SCREW,CAP-HFH M10X1.25X16 CL10.9 Z&Y | 1 | $1.50 | |
| 6 | 8422-002 | NUT,HEX-THK NYL M10X1.25 CL8 Z&Y | 1 | $0.95 | |
| 7 | 0423-335 | SCREW, CAP-HFH M10-1.25 X135 Z&Y CL10.9 | 1 | $12.35 | |
| 8 | 0423-073 | WASHER,FLAT-1.38 OD X .413 ID X.134 TH | 1 | $1.50 | |
| 9 | 1402-434 | BUSHING,SWAYBAR LINK | 1 | $12.35 | |
| 10 | 0423-620 | SPACER,SWAYBAR | 1 | $6.47 |
