CRANK BALANCER ASSEMBLY
2011 650 H1 MUD PRO
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0826-033 | SCREW,CAP HFH, M10X1.25X20 W/THD LOCK | 1 | $5.37 | |
| 2 | 0828-003 | WASHER,STEEL10 x 30 x 2.5 | 1 | $4.54 | |
| 3 | 0811-003 | R/B 0811-038 | 1 | $72.95 | |
| 4 | 0829-007 | DOWEL, SOLID, 4 x 6 | 1 | $12.35 | |
| 5 | 0811-004 | SPACER, DRIVE GEAR | 1 | $17.87 | |
| 6 | 0811-034 | GEAR,DRIVEN BALANCE SHAFT | 1 | $114.95 | |
| 7 | 0829-006 | WOODRUFF, CB SHAFT | 1 | $4.13 | |
| 8 | 0805-304 | BALANCER,CRANK MACHING-K | 1 | $169.95 |
