SWAY BAR ASSEMBLY
2012 PROWLER 700 HDX
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0504-634 | SWAYBAR,REAR-PTD BLK | 1 | $140.95 | |
| 2 | 8409-016 | SCREW,CAP-HFH M10X1.25X16 CL10.9 Z&Y | 1 | $1.50 | |
| 3 | 0504-631 | CLAMP,SWAYBAR BUSHING BLACK-PTD | 1 | $19.25 | |
| 4 | 0404-190 | BUSHING,HALF-SWAYBAR | 1 | $12.35 | |
| 5 | 0423-723 | SCREW,CAP-HFH M10-1.25X170 Z&Y CL 10.9 | 1 | $16.49 | |
| 6 | 0423-073 | WASHER,FLAT-1.38 OD X .413 ID X.134 TH | 1 | $1.50 | |
| 7 | 1402-434 | BUSHING,SWAYBAR LINK | 1 | $12.35 | |
| 8 | 1423-039 | SPACER,SWAYBAR | 1 | $5.78 |
