SECONDARY DRIVE ASSEMBLY

2014 WILDCAT 4X

Scroll / pinch to zoom · drag to pan · double-click resets

#	Part No.	Description	Qty	Price
1	0827-013	NUT,HEX SHOULDER M16X1.5	1	$3.02
2	0828-020	WASHER, STEEL, 16.3 x 30 x 3	1	$3.30
3	0819-126	FLANGE,OUTPUT DRIVE-ASSY	1	$85.95
4	0830-043	SEAL,OIL-DRIVEN SHAFT	1	$6.89
5	0832-017	R/B 0832-107	1	$125.95
6	0828-021	SHIM, 25 x 34 x .25	1	$2.47
6	0828-022	SHIM, 25 x 34 x .30	1	$8.21
6	0828-023	SHIM, 25 X 34 X 0.35 MM	1	$17.87
6	0828-024	SHIM,. 25 x 34 x .90	1	$17.87
6	0828-025	SHIM, 25 x 34 x .95	1	$17.87
6	0828-026	SHIM, 25 x 34 x 1.00	1	$17.87
6	0828-027	SHIM, 25 x 34 x 1.05	1	$17.87
6	0828-028	SHIM, 25 x 34 x 1.10	1	$16.49
6	0828-029	SHIM, 25 x 34 x 1.15	1	$17.87
7	0819-115	SECONDARY DRIVE SHAFT,17MM	1	$177.95
8	0819-011	RING, DRIVEN BEARING	1	$17.87
9	0832-016	BEARING, DRIVEN GEAR	1	$50.95
10	0822-106	GEAR,SECONDARY DRIVEN (GB-DN)	1	$129.95
11	0819-122	SHAFT,SEC. DRIVEN-REAR-CRWN SPLINE	1	$149.95
12	0831-011	RING, EXTERNAL RETAINING - DSH-25	1	$3.44
13	0830-214	R/B 0830-270	1	$13.95
14	0827-070	NUT,HEX-COLLARED (M20X1.5)	1	$20.63
15	0828-019	WASHER,THRUST, SECONDARY TRANSMISSION	1	$8.21
16	0822-153	GEAR,SECONDARY DRIVE-NF 37.5 PA	1	$156.95
17	0828-143	SHIM, 25.4 X 40 X 0.25	1	$37.95
17	0828-144	SHIM, 25.4 X 40 X 0.30	1	$37.95
17	0828-145	SHIM, 25.4 X 40 X 0.35	1	$38.95
17	0828-146	SHIM, 25.4 X 40 X 0.90	1	$38.95
17	0828-138	SHIM, 25.4 X 40 X .95	1	$38.95
17	0828-139	SHIM, 25.4 X 40 X 1.00	1	$38.95
17	0828-140	SHIM, 25.4 X 40 X 1.05	1	$38.95
17	0828-141	SHIM, 25.4 X 40 X 1.10	1	$38.95
17	0828-142	SHIM, 25.4 X 40 X .85	1	$38.95
18	0822-150	GEAR,DRIVEN-33T	1	$126.95
19	0832-083	BEARING,6306NR-W/SNAP RING	1	$54.95
20	0822-152	SHAFT,PINION	1	$114.95
21	0832-050	BEARING,CONRAD-6304	1	$20.63
