THROTTLE BODY ASSEMBLY
2015 XC 450 EFI
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0570-328 | THROTTLE BODY ASSY | 1 | $873.95 | |
| 2 | 3306-267 | SCREW-WASH.,4X28 | 1 | $9.59 | |
| 3 | 3306-266 | SCREW-WASH 4X14 | 1 | $9.59 | |
| 4 | 0824-060 | COVER,WIRE STAY | 1 | $4.26 | |
| 5 | 0835-007 | SCREW WASHER 4*12 (C) | 1 | $0.85 | |
| 6 | 0824-052 | SENSOR,T-MAP | 1 | $225.95 | |
| 7 | 0832-088 | SEAL,IDLE SPEED ACTUATOR | 1 | $1.78 | |
| 8 | 0824-054 | ACTUATOR,IDLE SPEED (ISA) | 1 | $212.95 | |
| 9 | 3305-953 | SCREW PAN 5*12 (C) (yellow zinc plated) | 1 | $1.09 | |
| 10 | 0824-053 | SENSOR,THROTTLE POSITION (TPS) | 1 | $64.95 | |
| 12 | 3306-251 | R/B 0470-884 | 1 | $135.95 | |
| 13 | 3307-074 | O-RING A INJECTOR /BLACK | 1 | $12.35 | |
| 14 | 3307-075 | O-RING B INJECTOR /GREEN | 1 | $12.35 | |
| 15 | 3306-253 | CLIP SPRING FUEL INJECTOR | 1 | $4.82 | |
| 16 | 3305-344 | BOLT FLANGE 6*16 | 1 | $1.09 | |
| 17 | 3307-073 | HOLDER ASSY FUEL INJECTOR | 1 | $12.35 | |
| 18 | 3306-250 | CLAMP,D60 | 1 | $10.97 | |
| 19 | 3306-275 | CABLE COMP, THROT | 1 | $26.95 |
