MAGNETO ASSEMBLY
2017 ALTERRA 400
Scroll / pinch to zoom · drag to pan · double-click resets
| # |
Part No. |
Description |
Qty |
Price |
|
| 1 |
3323-200 |
STATOR,IGNITION |
1 |
$205.95 |
|
| 2 |
3323-164 |
FLYWHEEL,IGNITION |
1 |
$260.95 |
|
| 4 |
0829-039 |
KEY WAY ACG |
1 |
$3.57 |
|
| 5 |
0827-046 |
NUT,HEX FLANGE,M16X1.5 |
1 |
$17.95 |
|
| 6 |
3307-059 |
BOLT HEX 5*12 (G) |
1 |
$2.75 |
|
| 7 |
0802-003 |
CLAMP, MAGNETO |
1 |
$3.44 |
|
| 8 |
0802-004 |
CLAMP, MAGNETO |
1 |
$3.44 |
|
