2017 Arctic Cat ALTERRA 90 — KICK STARTER AND COOLING DUCT ASSEMBLY
2017 ALTERRA 90
Scroll / pinch to zoom · drag to pan · double-click resets
| # |
Part No. |
Description |
Qty |
Price |
|
| 1 |
3303-123 |
ARM ASSY KICK STARTER |
1 |
$54.95 |
|
| 2 |
3305-247 |
E-RING 10mm |
1 |
$1.78 |
|
| 3 |
3305-195 |
WASHER PLAIN 13MM |
1 |
$0.81 |
|
| 4 |
3304-551 |
BOLT FLANGE 6*22 |
1 |
$0.81 |
|
| 5 |
3303-010 |
DUCT L COVER |
1 |
$23.39 |
|
| 6 |
3303-074 |
CLIP HOSE |
1 |
$3.16 |
|
| 7 |
3303-287 |
BAND ASSY AIR/C TUBE |
1 |
$8.21 |
|
