2017 Arctic Cat PROWLER 500 — BATTERY AND STARTER ASSEMBLY
2017 PROWLER 500
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3305-954 | MOTOR UNIT STARTER | 1 | $324.95 | |
| 2 | 3304-104 | O-RING 24.4*3.1 | 1 | $1.95 | |
| 3 | 3411-011 | DECAL,CREST (XC 450) | 1 | $66.95 | |
| 5 | 3305-251 | BOOT,STARTING MOTOR TERMINAL | 1 | $3.57 | |
| 8 | 3304-434 | BAND BATTERY | 1 | $13.73 | |
| 9 | 3306-301 | BATTERY YTX20L-BS | 1 | $409.95 | |
| 10 | 0445-082 | HARDWARE,BATTERY-PACK (010 ATV) | 1 | $10.97 | |
| 12 | 3304-061 | NUT CLIP 5MM | 1 | $2.33 | |
| 13 | 3304-565 | BOLT FLANGE 8*20 | 1 | $1.50 | |
| 16 | 3313-464 | RELAY,STARTER | 1 | $47.95 | |
| 17 | 3304-212 | BLADE FUSE 30A | 1 | $4.95 | |
| 18 | 3304-654 | NUT FLANGE 6MM | 1 | $1.23 |
