STEERING ASSEMBLY
2017 PROWLER 500
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 9 | 3305-513 | BOLT FLANGE 8*40(G) | 1 | $1.78 | |
| 10 | 3304-668 | NUT FLANGE 8MM | 1 | $0.81 | |
| 12 | 3304-572 | BOLT FLANGE 8*35 | 1 | $2.06 | |
| 15 | 3323-127 | SCREW-SHOULDER TSPH M6-1.0X18MM | 1 | $4.13 | |
| 16 | 3307-058 | NUT FLANGE 10MM | 1 | $5.09 | |
| 18 | 3304-176 | BOLT FLANGE 8*28 | 1 | $1.50 | |
| 22 | 0405-395 | R/B 0505-745 | 1 | $27.95 | |
| 25 | 3304-136 | WASHER PLAIN 10MM | 1 | $0.81 | |
| 26 | 3304-130 | NUT CASTLE 10MM | 1 | $3.30 | |
| 27 | 3304-143 | PIN SPLIT 2.5*30 | 1 | $1.37 | |
| 28 | 3304-548 | BOLT FLANGE 10*70 | 1 | $3.30 |
