FRONT DRIVE SYSTEM ASSEMBLY
2017 WILDCAT TRAIL SE EPS
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0410-070 | HOSE,FUEL-25 FT (0419-272 CTL) | 1 | $66.95 | |
| 2 | 1623-729 | SCREW,CAP-HFH M10-1.25X145 CL10.9 | 1 | $17.87 | |
| 3 | 0423-426 | WASHER,FLAT-.438X.875X.125 | 1 | $0.68 | |
| 4 | 1423-179 | SPACER,STL-10.5ID X 25.4OD X 19.5LG | 1 | $6.20 | |
| 6 | 0423-393 | CLAMP,42mm DIA - BOOT | 1 | $4.40 | |
| 7 | 0402-985 | BOOT,COUPLER (TBX) | 1 | $6.75 | |
| 8 | 0423-411 | CLAMP,30MM-BOOT | 1 | $4.26 | |
| 9 | 1423-090 | O-RING (2-115) | 1 | $1.64 | |
| 10 | 2402-099 | SHAFT,PROPELLER-FRONT | 1 | $251.95 | |
| 11 | 1423-175 | RING,RETAINING-EXTERNAL (30MM SHAFT) | 1 | $1.92 | |
| 12 | 5506-079 | BRACKET,FRONT DRIVE-PTD BLACK | 1 | $20.63 | |
| 13 | 1402-968 | BEARING,SHAFT CARRIER | 1 | $49.95 | |
| 14 | 8408-020 | SCREW,CAP-HFH M10X1.25X20 CL8.8 Z&Y | 1 | $3.16 | |
| 15 | 8422-002 | NUT,HEX-THK NYL M10X1.25 CL8 Z&Y | 1 | $0.95 | |
| 16 | 8408-816 | SCREW,CAP-HFH M8X1.25X16 CL8.8 Z&Y | 1 | $0.68 | |
| 17 | 2402-100 | SHAFT,PROPELLER-MID FRONT | 1 | $238.95 | |
| 18 | 0123-788 | TIE,CABLE-8.5/7.5/7.4 | 1 | $0.12 |
