1974 Arctic Cat CHEETAH 340 — CONSOLE AND WIRING
1974 CHEETAH 340
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 5 | 0116-074 | SNAP,BODY-CUSHION 61-0393-1183 | 1 | $1.64 | |
| 8 | 0106-333 | BUSHING,RECOIL | 1 | $30.95 | |
| 11 | 0123-214 | RECEPTACLE CLIP ON 5 | 1 | $12.35 | |
| 15 | 0109-563 | CABLE,CHOKE | 1 | $13.95 | |
| 16 | 0109-449 | SWITCH,ROCKER-ON/OFF | 1 | $74.95 | |
| 22 | 0123-254 | WASHER,FLAT 11/64X1/2 RUBB | 1 | $0.12 | |
| 23 | 0123-490 | NUT,SPEED 5/32 | 1 | $1.50 | |
| 25 | 0609-278 | SWITCH, IGN.-E.S.-N.O. | 1 | $71.95 | |
| 26 | 0109-555 | HARNESS,MAIN IGNITION | 1 | $81.95 | |
| 28 | 0123-394 | CLIP CABLE | 1 | $1.37 | |
| 29 | 0123-510 | SPRING,EXTN-HARNESS 4.50 | 1 | $30.95 | |
| 30 | 0123-597 | NUT,LOCK-W/WASHER 1/4-20 | 1 | $0.36 | |
| 31 | 0232-014 | REGULATOR,VOLTAGE | 1 | $75.95 | |
| 32 | 8050-157 | WASHER,FLAT- #10 X .500 X .049 Z&Y | 1 | $1.23 | |
| 33 | 8001-044 | SCREW,CAP-HH 1/4-20X1.25 G2 Z&Y | 1 | $0.15 | |
| 35 | 0123-788 | TIE,CABLE-8.5/7.5/7.4 | 1 | $0.12 | |
| 37 | 0609-412 | KEY, IGN. SWITCH | 1 | $20.63 | |
| 37 | 0109-354 | KEY IGN SWITCH C | 1 | $4.26 | |
| 37 | 0109-355 | KEY IGN SWITCH D.. | 1 | $16.49 | |
| 37 | 0109-356 | KEY IGN SWITCH E | 1 | $14.95 |
