1974 Arctic Cat EL TIGRE 400 — FUEL TANK, SEAT AND TRACK
1974 EL TIGRE 400
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 5 | 0123-729 | RIVET,SOLID .187X.562 STL | 1 | $1.78 | |
| 6 | 0116-378 | SNAP,ASSY BLACK-CUSHION | 1 | $1.23 | |
| 10 | 0109-362 | CAP & GAUGE ASS'Y - GAS TANK | 1 | $79.95 | |
| 16 | 0610-017 | HOSE,GAS 3/16 X100' | 1 | $232.95 | |
| 19 | 0470-988 | FILTER,FUEL-INLINE | 1 | $17.87 |
