1975 Arctic Cat EL TIGRE 440 — HOOD
1975 EL TIGRE 440
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 3 | 0123-551 | E-RING,EXTERNAL .250 | 1 | $1.95 | |
| 4 | 8008-610 | R/B 8007-610 | 1 | $0.25 | |
| 5 | 8040-366 | NUT,HEX LOCK-NYL 1/4-20 Z&Y | 1 | $0.26 | |
| 8 | 8060-508 | RIVET,BLIND-DH SS56 BLK | 1 | $0.26 | |
| 9 | 0123-254 | WASHER,FLAT 11/64X1/2 RUBB | 1 | $0.12 | |
| 10 | 0123-490 | NUT,SPEED 5/32 | 1 | $1.50 | |
| 14 | 0211-247 | DECAL,HOOD-440 | 1 | $15.95 | |
| 16 | 0116-376 | LATCH,HOOD | 1 | $31.95 | |
| 18 | 8050-217 | WASHER,FLAT- 1/4 X .625 X .065 Z&Y | 1 | $0.12 | |
| 19 | 0116-827 | STRAP,LATCH-HOOD | 1 | $14.95 | |
| 20 | 0123-596 | CLIP,PUSH | 1 | $1.95 | |
| 26 | 0123-549 | SCREW,MACH-PHTRH 10-32 X 1.00 Z&Y | 1 | $0.29 | |
| 27 | 0123-010 | NUT,EXPANSION 10-32 | 1 | $6.75 | |
| 31 | 0717-078 | FOAM,HOOD-CONVOLUTED 27 X 3'X.75 | 1 | $24.77 |
