1975 Arctic Cat PANTERA 340 — SKI
1975 PANTERA 340
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 2 | 1703-529 | SKAG-PTD BLK | 1 | $19.25 | |
| 3 | 8040-486 | NUT,HEX LOCK-NYL 3/8-16 Z&Y | 1 | $0.26 | |
| 4 | 8040-426 | NUT,HEX LOCK-NYL 5/16-18 Z&Y | 1 | $0.40 | |
| 6 | 8061-486 | RIVET,BLIND-LF SS54 ZINC | 1 | $1.09 | |
| 7 | 8002-140 | SCREW,CAP-HH 5/16-18 X2.75 G5 Z&Y | 1 | $1.23 | |
| 9 | 0103-339 | BLOCK, BUMP OUT | 1 | $49.95 | |
| 11 | 8050-242 | WASHER,FLAT- 5/16 X .625 X .063 Z&Y | 1 | $2.06 | |
| 12 | 0103-035 | SPRING,SINGLE LEAF | 1 | $100.95 | |
| 14 | 8002-225 | SCREW,CAP-HH 3/8-16 X1.50 G5 Z&Y | 1 | $0.95 | |
| 15 | 0123-389 | SCREW,CAP HEX 3/8-24X4-1/2 | 1 | $0.25 | |
| 20 | 8012-130 | SCREW, CAP -HHNLP 5/16-18X.75 G5 Z&Y | 1 | $12.35 | |
| 21 | 8002-318 | SCREW,CAP-HH 7/16-14 X2.25 G5 Z&Y | 1 | $2.95 | |
| 22 | 0106-195 | SLEEVE,UPPER | 1 | $31.95 | |
| 24 | 8040-546 | NUT,HEX LOCK-NYL 7/16-14 Z&Y | 1 | $0.45 | |
| 25 | 0106-198 | SPACER,NYLON | 1 | $34.95 | |
| 26 | 0106-196 | SLEEVE,LOWER | 1 | $22.95 | |
| 27 | 8002-322 | SCREW,CAP-HH 7/16-14 X3.25 G5 Z&Y | 1 | $1.95 | |
| 28 | 8002-232 | SCREW,CAP-HH 3/8-16 X3.25 G5 Z&Y | 1 | $2.06 | |
| 29 | 8040-516 | NUT,HEX LOCK-NYL 3/8-24 Z&Y | 1 | $0.68 |
