1975 Arctic Cat PANTERA 440 — CONSOLE AND WIRING
1975 PANTERA 440
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 2 | 0123-490 | NUT,SPEED 5/32 | 1 | $1.50 | |
| 2 | 8060-426 | RIVET,BLIND-DH AA54 BLK | 1 | $0.12 | |
| 3 | 0123-254 | WASHER,FLAT 11/64X1/2 RUBB | 1 | $0.12 | |
| 4 | 0609-412 | KEY, IGN. SWITCH | 1 | $20.63 | |
| 4 | 0109-354 | KEY IGN SWITCH C | 1 | $4.26 | |
| 4 | 0109-355 | KEY IGN SWITCH D.. | 1 | $16.49 | |
| 4 | 0109-356 | KEY IGN SWITCH E | 1 | $14.95 | |
| 5 | 8008-582 | SCREW,MACH-SLTH 1/4-20X1.0 G2 Z&Y | 1 | $0.25 | |
| 6 | 8008-607 | SCREW,MACH-SLTH 1/4-20X.50 G2 BE | 1 | $0.15 | |
| 7 | 0123-539 | NUT,SPEED 1/4-20 U-TYPE | 1 | $0.65 | |
| 9 | 8060-484 | RIVET, BLIND-DH SS53 ZINC | 1 | $0.40 | |
| 9 | 0123-402 | NUT,RETAINING | 1 | $0.75 | |
| 10 | 0116-074 | SNAP,BODY-CUSHION 61-0393-1183 | 1 | $1.64 | |
| 13 | 0106-333 | BUSHING,RECOIL | 1 | $30.95 | |
| 13 | 0123-214 | RECEPTACLE CLIP ON 5 | 1 | $12.35 | |
| 15 | 0109-601 | CABLE,CHOKE | 1 | $14.95 | |
| 16 | 0109-449 | SWITCH,ROCKER-ON/OFF | 1 | $74.95 | |
| 16 | 0109-563 | CABLE,CHOKE | 1 | $13.95 | |
| 24 | 0609-278 | SWITCH, IGN.-E.S.-N.O. | 1 | $71.95 | |
| 25 | 8007-584 | SCREW,MACH-CRTH 1/4-20X1.25 G2 Z&Y | 1 | $2.19 | |
| 26 | 0232-014 | REGULATOR,VOLTAGE | 1 | $75.95 | |
| 27 | 8050-217 | WASHER,FLAT- 1/4 X .625 X .065 Z&Y | 1 | $0.12 | |
| 27 | 8006-399 | SCREW, CAP-HSH 10-32X.625 Z&Y | 1 | $0.25 | |
| 28 | 8040-366 | NUT,HEX LOCK-NYL 1/4-20 Z&Y | 1 | $0.26 | |
| 28 | 8050-157 | WASHER,FLAT- #10 X .500 X .049 Z&Y | 1 | $1.23 | |
| 29 | 0123-394 | CLIP CABLE | 1 | $1.37 | |
| 30 | 8040-276 | NUT,HEX LOCK-NYL 10-32 Z&Y | 1 | $0.15 | |
| 31 | 0123-510 | SPRING,EXTN-HARNESS 4.50 | 1 | $30.95 | |
| 32 | 8008-610 | R/B 8007-610 | 1 | $0.25 | |
| 33 | 0123-269 | CLAMP,CABLE,11/16 INSUL | 1 | $2.75 | |
| 34 | 0123-397 | CLAMP CABLE NYLON 5/16 | 1 | $0.75 | |
| 37 | 0123-788 | TIE,CABLE-8.5/7.5/7.4 | 1 | $0.12 | |
| 40 | 0123-149 | WSHR,FLAT 11/64X3/8X.030TH Z&Y | 1 | $2.06 | |
| 43 | 0123-053 | WASHER, FLAT 5/16 X 3/4 | 1 | $1.64 |
