1975 Arctic Cat PANTHER 440 — FAN
1975 PANTHER 440
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 2 | 3000-268 | PIN,DOWEL | 1 | $2.95 | |
| 3 | 3007-415 | STUD BOLT | 1 | $4.95 | |
| 4 | 3423-204 | WASHER | 1 | $1.95 | |
| 6 | 3007-416 | NUT | 1 | $2.75 | |
| 7 | 3000-165 | COOLING FAN ASSY | 1 | $133.95 | |
| 8 | 3000-434 | BEARING,BALL,M20X47X14 | 1 | $46.95 | |
| 11 | 3000-266 | KEY(FASTENER) | 1 | $3.30 | |
| 13 | 3000-170 | PULLEY,FAN | 1 | $48.95 | |
| 14 | 3000-271 | SHIM | 1 | $2.95 | |
| 15 | 3007-427 | LOCK WASHER | 1 | $4.40 | |
| 18 | 3000-454 | SCREW 4 X 20 | 1 | $0.58 | |
| 23 | 0109-527 | HOUSING SOCKET 1-4 | 1 | $4.09 |
