1977 Arctic Cat EL TIGRE 4000 — CONSOLE AND WIRING
1977 EL TIGRE 4000
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 2 | 0123-596 | CLIP,PUSH | 1 | $1.95 | |
| 3 | 8008-610 | R/B 8007-610 | 1 | $0.25 | |
| 4 | 0123-539 | NUT,SPEED 1/4-20 U-TYPE | 1 | $0.65 | |
| 5 | 0687-007 | CABLE,CHOKE-DUAL | 1 | $84.95 | |
| 7 | 8002-040 | SCREW,CAP-HH 1/4-20 X.75 G5 Z&Y | 1 | $0.40 | |
| 10 | 8060-286 | RIVET,BLIND-DH SS44 ZINC | 1 | $0.68 | |
| 12 | 0609-111 | NUT,RETAINING-5/8-32UN2B BLK PLASTIC | 1 | $6.47 | |
| 13 | 0116-065 | KEY,IGNITION | 1 | $8.21 | |
| 19 | 8040-366 | NUT,HEX LOCK-NYL 1/4-20 Z&Y | 1 | $0.26 | |
| 20 | 0630-001 | REGULATOR,VOLTAGE | 1 | $66.95 | |
| 22 | 0109-822 | SWITCH,IGNITION | 1 | $68.95 | |
| 23 | 0123-149 | WSHR,FLAT 11/64X3/8X.030TH Z&Y | 1 | $2.06 | |
| 24 | 0123-397 | CLAMP CABLE NYLON 5/16 | 1 | $0.75 | |
| 27 | 0123-394 | CLIP CABLE | 1 | $1.37 | |
| 28 | 1623-984 | CLAMP,WIRE - 76.14MM LG W/6.25 HOLE | 1 | $6.20 | |
| 29 | 0123-788 | TIE,CABLE-8.5/7.5/7.4 | 1 | $0.12 | |
| 30 | 0120-332 | CABLE,SPEEDOMETER | 1 | $60.95 | |
| 32 | 3004-447 | WASHER, LOCK 6MM | 1 | $3.16 | |
| 33 | 0120-281 | BRACKET,MTG-TACHOMETER | 1 | $13.73 |
