1979 Arctic Cat PANTERA — HOOD
1979 PANTERA
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 2 | 0211-724 | DECAL,ARCTIC CAT | 1 | $39.95 | |
| 3 | 0211-775 | DECAL,SIDE LEFT | 1 | $50.95 | |
| 4 | 0211-773 | DECAL,HOOD LH TOP | 1 | $26.95 | |
| 5 | 8040-366 | NUT,HEX LOCK-NYL 1/4-20 Z&Y | 1 | $0.26 | |
| 6 | 8050-217 | WASHER,FLAT- 1/4 X .625 X .065 Z&Y | 1 | $0.12 | |
| 7 | 0116-376 | LATCH,HOOD | 1 | $31.95 | |
| 9 | 0123-765 | WASHER,CUP .265X1.06 12 GA | 1 | $5.78 | |
| 10 | 0116-827 | STRAP,LATCH-HOOD | 1 | $14.95 | |
| 13 | 0123-596 | CLIP,PUSH | 1 | $1.95 | |
| 15 | 0220-013 | TRIM,PLASTIC-HOOD-59.5 | 1 | $24.95 | |
| 16 | 0123-549 | SCREW,MACH-PHTRH 10-32 X 1.00 Z&Y | 1 | $0.29 | |
| 18 | 0123-010 | NUT,EXPANSION 10-32 | 1 | $6.75 | |
| 22 | 0123-615 | NUT,ADJUSTMENT | 1 | $4.54 | |
| 23 | 0109-724 | R/B 0609-956 | 1 | $29.95 | |
| 24 | 0123-614 | SPRING,ADJUSTMENT | 1 | $1.92 | |
| 26 | 8009-430 | SCREW,MACH-CRPH 10-24X.75 G2 Z&BLK | 1 | $0.95 | |
| 27 | 8050-157 | WASHER,FLAT- #10 X .500 X .049 Z&Y | 1 | $1.23 | |
| 28 | 8040-246 | NUT,HEX LOCK-NYL 10-24 Z&Y | 1 | $0.26 | |
| 29 | 0116-867 | HEADLIGHT BEZEL | 1 | $47.95 | |
| 30 | 0717-078 | FOAM,HOOD-CONVOLUTED 27 X 3'X.75 | 1 | $24.77 | |
| 30 | 0116-914 | INSULATION,HOOD-RIGHT | 1 | $61.95 | |
| 32 | 0130-002 | VENT,FRONT 106-694 2ND | 1 | $125.95 | |
| 33 | 0106-738 | VENT, HOOD-TOP | 1 | $27.95 | |
| 34 | 0123-149 | WSHR,FLAT 11/64X3/8X.030TH Z&Y | 1 | $2.06 | |
| 35 | 8061-710 | RIVET,BLIND-LF SS68 BLACK | 1 | $1.09 | |
| 36 | 0116-993 | HINGE,HOOD-UPPER-WELDMT | 1 | $93.95 |
