1989 Arctic Cat PANTERA (440 L/C) — ELECTRIC START ASSEMBLY
1989 PANTERA (440 L/C)
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0745-357 | R/B 0745-434 | 1 | $497.95 | |
| 3 | 0637-265 | UPDATE KIT,STARTER PINION DRIVE(4-1-2) | 1 | $92.95 | |
| 4 | 0639-197 | KIT, ENDCAP REPLACEMENT | 1 | $121.95 | |
| 6 | 0645-275 | KIT, BRUSH & SPRING-ES HD SHORT | 1 | $71.95 | |
| 7 | 0645-053 | BOLT,STARTER MOTOR | 1 | $4.95 | |
| 8 | 0645-054 | COMMUTATOR CAP | 1 | $225.95 | |
| 10 | 0623-093 | BOLT, 5/16-18X1 1/2 RIBBED | 1 | $2.47 | |
| 11 | 0645-082 | WRAP,BATTERY HEAT-6 X 11 | 1 | $6.34 | |
| 12 | 8040-426 | NUT,HEX LOCK-NYL 5/16-18 Z&Y | 1 | $0.40 | |
| 14 | 8002-040 | SCREW,CAP-HH 1/4-20 X.75 G5 Z&Y | 1 | $0.40 | |
| 15 | 8051-217 | WASHER,SPR LOCK-1/4 .252X.489X.077 Z&Y | 1 | $0.35 | |
| 16 | 0686-042 | HARNESS,ELECTRIC START | 1 | $68.95 | |
| 17 | 0645-078 | SOLENOID,ELECTRIC START(COMES W/ KIT 1) | 1 | $106.95 | |
| 18 | 0645-016 | CABLE, SOL-STARTER 21 | 1 | $56.95 | |
| 19 | 8040-366 | NUT,HEX LOCK-NYL 1/4-20 Z&Y | 1 | $0.26 | |
| 20 | 8050-217 | WASHER,FLAT- 1/4 X .625 X .065 Z&Y | 1 | $0.12 | |
| 22 | 8051-152 | WASHER,SPR LOCK-#10 .193X.334X.047 Z&Y | 1 | $0.15 | |
| 23 | 8042-272 | NUT,10-32 HEX-REG-GR2 Z&Y | 1 | $0.15 | |
| 24 | 8051-242 | WASHER,SPR LOCK-5/16 .314X.583X.078 Z&Y | 1 | $1.64 | |
| 25 | 8043-452 | NUT,5/16-24 HEX LOCK-MET TOP LOC GRA Z&Y | 1 | $0.95 | |
| 26 | 0645-015 | CABLE,BATT-SOL 14.3 | 1 | $53.95 | |
| 27 | 0645-080 | CABLE,BATT-GRD 30 | 1 | $30.95 | |
| 28 | 0745-040 | BATTERY PKG(0645-063) | 1 | $113.95 | |
| 29 | 0645-086 | STRAP,BATTERY-TOP | 1 | $15.95 | |
| 30 | 0645-019 | BOOT,TERMINAL-BATTERY | 1 | $4.40 | |
| 32 | 0645-061 | ROD,HOLDING-BATTERY | 1 | $19.25 | |
| 33 | 0123-788 | TIE,CABLE-8.5/7.5/7.4 | 1 | $0.12 | |
| 34 | 0120-309 | GEAR,RING-ELECTRIC START | 1 | $288.95 | |
| 36 | 0123-903 | TIE,CABLE 11.50 | 1 | $0.54 |
