1991 Arctic Cat PROWLER — FRONT FRAME, BELLY PAN AND FOOTREST ASSEMBLY
1991 PROWLER
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0707-222 | FRONT END-CHASIS W/RIVETS | 1 | $704.95 | |
| 2 | 0707-077 | SUPPORT,BEARING-WELDMENT | 1 | $94.95 | |
| 5 | 8040-246 | NUT,HEX LOCK-NYL 10-24 Z&Y | 1 | $0.26 | |
| 6 | 8002-039 | SCREW,CAP-HH 1/4-20 X.625 G5 Z&Y | 1 | $0.40 | |
| 7 | 8040-366 | NUT,HEX LOCK-NYL 1/4-20 Z&Y | 1 | $0.26 | |
| 8 | 0707-840 | PLATE,BEARING MTG-PTD BLK | 1 | $23.39 | |
| 9 | 0707-086 | FRONT END-WELDT | 1 | $853.95 | |
| 10 | 0612-111 | BUMPER,MOLDED-RUBBER | 1 | $16.49 | |
| 11 | 0707-066 | SHIELD,CLUTCH-ASSY | 1 | $189.95 | |
| 12 | 0607-094 | INSERT,HINGE-GUARD | 1 | $0.95 | |
| 13 | 8002-052 | SCREW,CAP-HH 1/4-20 X3.25 G5 Z&Y | 1 | $0.95 | |
| 14 | 0607-095 | KNOB,THREADED MALE STUD | 1 | $24.77 | |
| 15 | 0607-097 | GROMMET,GUARD | 1 | $1.92 | |
| 16 | 8050-252 | WASHER,FLAT- 5/16 X .875 X .063 Z&Y | 1 | $0.68 | |
| 17 | 0607-096 | RETAINER,KNOB-CLUTCH SHLD | 1 | $20.63 | |
| 20 | 0606-477 | FENDER,INNER-LH | 1 | $157.95 | |
| 20 | 0606-476 | FENDER,INNER-RH | 1 | $157.95 | |
| 21 | 0605-122 | BOOT,STEERING-TIE ROD | 1 | $30.95 | |
| 22 | 0623-144 | TIE,CABLE-17.5 LONG | 1 | $0.54 | |
| 23 | 0123-539 | NUT,SPEED 1/4-20 U-TYPE | 1 | $0.65 | |
| 24 | 8017-610 | SCREW,MACH-TSTRH 1/4-20 X 3/4 GR2 BLK Z | 1 | $5.92 | |
| 25 | 8050-217 | WASHER,FLAT- 1/4 X .625 X .065 Z&Y | 1 | $0.12 | |
| 26 | 8061-506 | RIVET,BLIND-LF SS54 BLACK | 1 | $0.95 | |
| 27 | 8060-510 | RIVET,BLIND-DH SS58 BLK | 1 | $0.68 | |
| 28 | 0123-149 | WSHR,FLAT 11/64X3/8X.030TH Z&Y | 1 | $2.06 | |
| 29 | 0606-197 | FOOTREST-LH,PAINTED | 1 | $152.95 | |
| 29 | 0606-198 | FOOTREST-RH,PAINTED | 1 | $157.95 | |
| 30 | 0623-166 | RIVET,CHERRY-5/32 X 3/16 | 1 | $0.95 | |
| 31 | 8060-484 | RIVET, BLIND-DH SS53 ZINC | 1 | $0.40 | |
| 32 | 0606-654 | PLUG,HOLE-5/8 | 1 | $0.65 | |
| 33 | 8060-504 | RIVET,BLIND-DH SS53 BLK | 1 | $0.26 | |
| 35 | 0623-060 | SCREW,OVAL HEAD-1/4-20X1-1/2 | 1 | $1.64 | |
| 38 | 0605-120 | BRACE,STEERING SUPPORT-RH | 1 | $16.49 | |
| 38 | 0605-121 | BRACE,STEERING SUPPORT-LH | 1 | $16.95 | |
| 39 | 1705-114 | PLATE, BACKING TOP-PTD BLK | 1 | $8.95 | |
| 40 | 1705-113 | PLATE, BACKING SIDE-PTD BLK | 1 | $12.35 | |
| 41 | 0623-227 | SCREW,MACH FH CR 10-24 X 1.25 | 1 | $0.95 | |
| 42 | 0606-555 | BRKT,RECOIL BUSHING | 1 | $33.95 | |
| 43 | 8060-486 | RIVET, BLIND-DH SS54 ZINC | 1 | $0.40 | |
| 44 | 0706-371 | TRIM,RACK-36 | 1 | $20.63 | |
| 46 | 0116-469 | BUSHING, RECOIL | 1 | $5.51 | |
| 47 | 0606-481 | SPACER,POD LATCH | 1 | $10.97 | |
| 48 | 0115-306 | CORD,LATCH | 1 | $5.51 | |
| 49 | 0123-765 | WASHER,CUP .265X1.06 12 GA | 1 | $5.78 | |
| 50 | 8002-047 | SCREW,CAP-HH 1/4-20 X2.00 G5 Z&Y | 1 | $0.95 | |
| 51 | 0706-838 | BELLY PAN | 1 | $404.95 | |
| 52 | 8061-508 | RIVET,BLIND-LF SS56 BLACK | 1 | $1.37 | |
| 53 | 0606-671 | FOIL,BELLYPAN | 1 | $4.95 | |
| 55 | 0605-161 | PLATE,BACKING-FRONT COVER | 1 | $6.95 |
