WINDSHIELD, FAIRING, AND INSTRUMENTS
1994 PROWLER
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0606-722 | WINDSHIELD, SMOKE | 1 | $117.95 | |
| 2 | 0616-032 | O-RING-WINDSHIELD (1 I.D.) | 1 | $1.78 | |
| 4 | 0623-309 | SCREW, SELF TAP-PHPNH 12-11X3/4 A Z&B | 1 | $0.40 | |
| 6 | 0706-692 | ROD,WINDSHIELD-STRAIGHT-W/BALL | 1 | $79.95 | |
| 7 | 0605-157 | CAP,WINDSHIELD MOUNT | 1 | $3.85 | |
| 9 | 0616-120 | FAIRING,BLOW MOLDED | 1 | $62.95 | |
| 10 | 8050-157 | WASHER,FLAT- #10 X .500 X .049 Z&Y | 1 | $1.23 | |
| 11 | 8040-246 | NUT,HEX LOCK-NYL 10-24 Z&Y | 1 | $0.26 | |
| 12 | 1611-409 | DECAL,WARNING-GENERAL-FAIRING | 1 | $25.95 | |
| 14 | 0720-007 | TACHOMETER W/HARNESS | 1 | $347.95 | |
| 15 | 0620-090 | HARNESS,TACH.-REV,WRMR.& BTTRY REF0620-0 | 1 | $111.95 | |
| 16 | 0620-098 | BACKCLAMP,TACH/SPEEDO-3.56 | 1 | $3.71 | |
| 17 | 0620-091 | HARNESS,SPEEDO-BEAM,TEMP&OIL REF0620-062 | 1 | $90.95 | |
| 18 | 8051-152 | WASHER,SPR LOCK-#10 .193X.334X.047 Z&Y | 1 | $0.15 | |
| 19 | 8040-276 | NUT,HEX LOCK-NYL 10-32 Z&Y | 1 | $0.15 | |
| 20 | 0620-096 | RING,CUSHION-RUBBER | 1 | $17.87 | |
| 21 | 0620-104 | BULB,TACH/SPEEDO-1.5WT-1 1/4 | 1 | $4.68 | |
| 22 | 0620-087 | SPEEDOMETER,US (BACKLIT) | 1 | $264.95 | |
| 23 | 0620-105 | KNOB, TRIPMETER | 1 | $17.95 | |
| 24 | 0120-332 | CABLE,SPEEDOMETER | 1 | $60.95 | |
| 25 | 0620-279 | BULB,TACH SPEEDO ASSY | 1 | $5.95 |
