CONSOLE EXTENSION, SWITCHES, AND INSTRUMENTS
1994 THUNDERCAT
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0616-253 | EXTENSION,CONSOLE | 1 | $185.95 | |
| 2 | 1611-797 | DECAL,CONSOLE-SWITCH | 1 | $48.95 | |
| 3 | 0123-899 | WASHER,IGNITION | 1 | $0.95 | |
| 4 | 0123-900 | NUT,IGNITION | 1 | $1.95 | |
| 5 | 0609-412 | KEY, IGN. SWITCH | 1 | $20.63 | |
| 6 | 0609-081 | SWITCH, IGN. (W/0 KEY) | 1 | $54.95 | |
| 7 | 0636-062 | LEVER KIT,CHOKE | 1 | $12.35 | |
| 8 | 0687-041 | CABLE,CHOKE-TRIPLE | 1 | $120.95 | |
| 9 | 0623-165 | CLIP, X-MAS TREE-5/32 | 1 | $1.50 | |
| 10 | 0709-054 | TETHER SWITCH-ASSY (CLOSED) | 1 | $42.95 | |
| 11 | 0709-055 | TETHER CORD W/ SCREW | 1 | $34.95 | |
| 13 | 0123-641 | WASHER,FIBER-1/2X13/16X.030 | 1 | $4.95 | |
| 14 | 0123-985 | WASHER,INT LOCK .472 | 1 | $2.88 | |
| 15 | 0609-187 | SWITCH,TOGGLE-DPDT (THUMB/HAND WARMER) | 1 | $33.95 | |
| 16 | 0620-066 | SPEEDOMETER W/HI BEAM AND OIL LIGHTS | 1 | $369.95 | |
| 17 | 0620-073 | KNOB,TRIPMETER | 1 | $15.11 | |
| 18 | 0620-064 | HARNESS,SPEEDO-BEAM&OIL | 1 | $58.95 | |
| 19 | 0620-083 | CUSHION,RUBBER-SPEEDOMETER/TACH | 1 | $13.73 | |
| 20 | 0230-020 | BULB, T-10 WEDGE BASE-12 V 3.4W | 1 | $3.16 | |
| 21 | 0609-078 | BULB,T 6.5 WEDGE BASE-1 | 1 | $4.95 | |
| 22 | 0620-070 | TACHOMETER,ELECTRIC | 1 | $469.95 | |
| 23 | 0620-063 | HARNESS,TACH-TEMP&WARMER | 1 | $56.95 | |
| 24 | 1611-759 | DECAL,INSTRUMENT MTG. | 1 | $81.95 | |
| 25 | 0120-361 | PLATE,RETAINING | 1 | $5.95 | |
| 26 | 0120-281 | BRACKET,MTG-TACHOMETER | 1 | $13.73 | |
| 27 | 0120-457 | BRACKET,SPEEDOMETER-MTG | 1 | $17.87 | |
| 28 | 0623-038 | NUT,HEX M6 Z&Y-SEMS (W/WASHER) | 1 | $0.26 | |
| 29 | 0120-332 | CABLE,SPEEDOMETER | 1 | $60.95 | |
| 30 | 8050-157 | WASHER,FLAT- #10 X .500 X .049 Z&Y | 1 | $1.23 | |
| 31 | 0623-378 | SCREW,SELF TAP-PHTRH #8-32 X .50 AB Z&Y | 1 | $0.26 | |
| 32 | 0623-259 | CLIP,CHRISTMAS TREE-1/4 | 1 | $1.95 | |
| 33 | 0623-153 | WASHER,NYLON 1/2X5/8-.030 | 1 | $2.95 |
