REVERSE SHIFT LEVER ASSEMBLY
1996 BEARCAT 550
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0602-842 | REINFORCEMENT,SHIFT LEVER | 1 | $4.95 | |
| 2 | 0602-841 | BRACKET,SHIFT MOUNTING | 1 | $24.77 | |
| 3 | 8040-426 | NUT,HEX LOCK-NYL 5/16-18 Z&Y | 1 | $0.40 | |
| 4 | 8002-140 | SCREW,CAP-HH 5/16-18 X2.75 G5 Z&Y | 1 | $1.23 | |
| 5 | 0602-844 | BEARING, (GARLOCK 08DU08) SHOCK END .500 | 1 | $3.16 | |
| 6 | 0702-306 | LEVER,SHIFT-FAB | 1 | $154.95 | |
| 7 | 0602-851 | GRIP,HANDLE-SHIFT LEVER | 1 | $34.95 | |
| 8 | 0123-005 | NUT,JAM 1/2-13 | 1 | $3.16 | |
| 9 | 0602-845 | AXLE,SHIFT LEVER | 1 | $14.95 | |
| 10 | 0602-322 | ROD END,5/16-24-RH | 1 | $29.95 | |
| 11 | 0123-144 | NUT,HEX-JAM 5/16-24 NF ZN | 1 | $0.26 | |
| 12 | 0602-847 | ROD,SHIFTING-UPPER | 1 | $32.95 | |
| 13 | 0623-260 | NUT,HEX JAM 5/16-24 NF L H | 1 | $1.09 | |
| 14 | 0602-305 | ROD END L.H. 5/16-24 UNF | 1 | $22.95 | |
| 15 | 8002-132 | SCREW,CAP-HH 5/16-18 X1.00 G5 Z&Y | 1 | $0.95 | |
| 16 | 0702-289 | LINK,SHIFTING-UPPER | 1 | $129.95 | |
| 17 | 8002-142 | SCREW,CAP-HH 5/16-18 X3.25 G5 Z&Y | 1 | $0.65 | |
| 19 | 0123-053 | WASHER, FLAT 5/16 X 3/4 | 1 | $1.64 | |
| 20 | 0602-853 | AXLE,PIVOT LINK | 1 | $12.95 | |
| 21 | 8051-242 | WASHER,SPR LOCK-5/16 .314X.583X.078 Z&Y | 1 | $1.64 | |
| 22 | 0702-290 | LINK,SHIFTING-LOWER | 1 | $94.95 | |
| 24 | 8002-131 | SCREW,CAP-HH 5/16-18 X.875 G5 Z&Y | 1 | $0.95 | |
| 25 | 8051-212 | WASHER,SPR LOCK-1/4 .252X.487X.062 Z&Y | 1 | $0.12 | |
| 26 | 8002-037 | SCREW,CAP-HH 1/4-20 X.50 G5 Z&Y | 1 | $0.25 | |
| 27 | 0602-846 | GROMMET,SHIFT LEVER | 1 | $19.25 | |
| 28 | 0602-854 | BRACKET,REV.SWITCH | 1 | $138.95 | |
| 29 | 8041-426 | NUT,HEX THIN LOCK-NYL 5/16-18 Z&Y | 1 | $0.40 | |
| 30 | 0630-011 | SWITCH, ALARM | 1 | $60.95 | |
| 31 | 0630-013 | BOOT,SWITCH-REVERSE | 1 | $20.63 |
