1996 Arctic Cat COUGAR MOUNTAIN CAT — HOOD AND WINDSHIELD ASSEMBLY
1996 COUGAR MOUNTAIN CAT
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0718-319 | HOOD W/O DECAL95COUGAR | 1 | $1,515.95 | |
| 1 | 0718-394 | HOOD, W/GRAPHIC DECALS-96 CO/2UP | 1 | $1,905.95 | |
| 2 | 0717-066 | FOAM,HOOD-RH | 1 | $27.95 | |
| 2 | 0717-067 | FOAM,HOOD-LH | 1 | $29.95 | |
| 3 | 1611-754 | DECAL,ARCTIC CAT-WHITE | 1 | $19.95 | |
| 4 | 2611-266 | DECAL,HOOD-SIDE RH | 1 | $87.95 | |
| 4 | 2611-267 | DECAL,HOOD-SIDE LH | 1 | $87.95 | |
| 5 | 2611-270 | DECAL,HOOD-COUGAR-RH | 1 | $17.95 | |
| 5 | 2611-271 | DECAL,HOOD-COUGAR-LH | 1 | $17.95 | |
| 6 | 0616-662 | BAR,TIE-HOOD | 1 | $61.95 | |
| 7 | 8061-706 | RIVET,BLIND-LF SS64 BLACK | 1 | $0.95 | |
| 8 | 0616-673 | BRACKET,HOOD HINGE | 1 | $68.95 | |
| 9 | 1611-575 | DECAL,WARNING-HOOD | 1 | $25.95 | |
| 10 | 0717-062 | FOAM,HOOD-UPPER-RH | 1 | $13.95 | |
| 10 | 0717-063 | FOAM,HOOD-UPPER-LH | 1 | $13.95 | |
| 11 | 2611-158 | DECAL,CAUTION-ENGINE/BATTERY | 1 | $17.95 | |
| 12 | 0115-306 | CORD,LATCH | 1 | $5.51 | |
| 13 | 8040-366 | NUT,HEX LOCK-NYL 1/4-20 Z&Y | 1 | $0.26 | |
| 14 | 8009-614 | SCREW,MACH-CRPH 1/4-20X1.25 G2 Z&BLK | 1 | $0.25 | |
| 15 | 0623-261 | WASHER,CUP-1/4 X 1-BLK | 1 | $22.01 | |
| 16 | 8050-217 | WASHER,FLAT- 1/4 X .625 X .065 Z&Y | 1 | $0.12 | |
| 17 | 0616-539 | WINDSHIELD,SMOKE | 1 | $215.95 | |
| 18 | 0616-032 | O-RING-WINDSHIELD (1 I.D.) | 1 | $1.78 | |
| 19 | 0123-010 | NUT,EXPANSION 10-32 | 1 | $6.75 | |
| 20 | 0623-121 | SCREW,MACH-PHTRH #10-32X3/4 Z&Y | 1 | $4.82 | |
| 21 | 0124-054 | SNAP CAP W/WASHER | 1 | $1.23 | |
| 22 | 0616-813 | CABLE,HOOD-33.5 (.20 EYELET BOTH ENDS) | 1 | $26.95 | |
| 23 | 8061-708 | RIVET, BLIND-LF SS66 BLACK | 1 | $0.95 | |
| 24 | 0123-510 | SPRING,EXTN-HARNESS 4.50 | 1 | $30.95 | |
| 25 | 0616-753 | FOIL,HOOD-LOWER | 1 | $20.95 | |
| 26 | 2611-265 | DECAL,HOOD-NOSE | 1 | $76.95 | |
| 27 | 2611-268 | DECAL,HOOD-REAR RH | 1 | $32.95 | |
| 27 | 2611-269 | DECAL,HOOD-REAR LH | 1 | $32.95 | |
| 28 | 8061-710 | RIVET,BLIND-LF SS68 BLACK | 1 | $1.09 | |
| 29 | 0123-802 | WASHER,FLAT .194X.50X.048-Z&Y | 1 | $0.12 |
