1997 Arctic Cat POWDER SPECIAL EFI — SEAT AND TAILLIGHT ASSEMBLIES
1997 POWDER SPECIAL EFI
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0716-607 | R/B 0716-495 | 1 | $334.95 | |
| 2 | 0623-378 | SCREW,SELF TAP-PHTRH #8-32 X .50 AB Z&Y | 1 | $0.26 | |
| 3 | 1606-150 | WIRE, SEAT | 1 | $3.02 | |
| 4 | 0716-532 | FOAM,SEAT CUSHION 136" MC | 1 | $361.95 | |
| 5 | 0124-031 | SCREW,TAP HWH #10-24 X .375 | 1 | $13.73 | |
| 6 | 0624-528 | STAPLE,5/16L X 1/2W-20GA SS/5000 PAK-SEA | 1 | $161.95 | |
| 7 | 0606-029 | REFLECTOR, RED | 1 | $13.73 | |
| 8 | 0623-269 | CLIP, CHRISTMAS TREE | 1 | $1.23 | |
| 9 | 8061-426 | RIVET,BLIND-LF AA54 BLACK | 1 | $0.95 | |
| 10 | 0617-098 | FOAM, SEATBASE-TAIL LIGHT | 1 | $6.95 | |
| 11 | 8050-157 | WASHER,FLAT- #10 X .500 X .049 Z&Y | 1 | $1.23 | |
| 12 | 0616-022 | COVER,TUNNEL EXTENSION | 1 | $128.95 | |
| 13 | 0623-038 | NUT,HEX M6 Z&Y-SEMS (W/WASHER) | 1 | $0.26 | |
| 14 | 0623-184 | WASHER,FLAT 1/4 X 1.0 Z&Y | 1 | $1.95 | |
| 15 | 0109-460 | BULB,STOP/TAILLAMP | 1 | $2.06 | |
| 16 | 0609-093 | SCREW,RETAIN(M4X25 SELF TAPP) | 1 | $0.68 | |
| 17 | 0609-090 | LENS,TAILLIGHT | 1 | $30.95 | |
| 18 | 2611-658 | DECAL,POWDER SPECIAL/WARNING | 1 | $73.95 | |
| 19 | 0609-091 | HOUSING,TAILLIGHT WITH SOCKET & HARNESS | 1 | $81.95 | |
| 20 | 0609-092 | GASKET,TAILLIGHT | 1 | $13.73 |
