BELLY PAN AND FRONT BUMPER ASSEMBLY
1998 JAG 440
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 1606-172 | BELLYPAN-ROUTED-RH | 1 | $268.95 | |
| 1 | 1606-179 | BELLYPAN-ROUTED-LH | 1 | $365.95 | |
| 2 | 1606-065 | BUMPER, BELLYPAN-LH | 1 | $29.95 | |
| 3 | 0623-647 | SCREW,SELF TAP-HWH 1/4X2.0 A Z&Y | 1 | $0.95 | |
| 4 | 0623-184 | WASHER,FLAT 1/4 X 1.0 Z&Y | 1 | $1.95 | |
| 5 | 1606-094 | SUPPORT, BELLYPAN-RH | 1 | $23.39 | |
| 5 | 1606-095 | SUPPORT, BELLYPAN-LH | 1 | $26.95 | |
| 6 | 0623-301 | SCREW,SELF TAP-HWH 10X1/2 AB Z&Y | 1 | $0.12 | |
| 7 | 0606-526 | REFLECTOR,FRONT-YELLOW | 1 | $3.02 | |
| 8 | 0623-269 | CLIP, CHRISTMAS TREE | 1 | $1.23 | |
| 9 | 0605-332 | BOOT,STEERING-DRAG LINK-RH | 1 | $40.95 | |
| 9 | 0605-333 | BOOT,STEERING-DRAG LINK-LH | 1 | $28.95 | |
| 10 | 0623-564 | SCREW,TAPPING #10 X 1.00 HWH | 1 | $3.57 | |
| 11 | 0612-545 | RING,EXHAUST OUTLET-LOWER | 1 | $8.95 | |
| 12 | 0612-475 | BOOT,EXHAUST | 1 | $54.95 | |
| 13 | 0612-546 | RING,EXHAUST OUTLET-UPPER | 1 | $10.95 | |
| 14 | 8061-508 | RIVET,BLIND-LF SS56 BLACK | 1 | $1.37 | |
| 15 | 1606-044 | LOUVER, AIR INTAKE-RH-BLK | 1 | $46.95 | |
| 15 | 1606-045 | LOUVER, AIR INTAKE-LH-BLK | 1 | $46.95 | |
| 16 | 0123-149 | WSHR,FLAT 11/64X3/8X.030TH Z&Y | 1 | $2.06 | |
| 17 | 0623-600 | PLUG,BELLYPAN-2.00 | 1 | $4.82 | |
| 18 | 0623-700 | SCREW,SELF TAP-TSTRH #10-12X3/4 TP A Z&Y | 1 | $10.95 | |
| 19 | 0616-999 | BUMPER, FRONT | 1 | $110.95 | |
| 21 | 8050-222 | WASHER,FLAT- 1/4 X .734 X .063 Z&Y | 1 | $0.68 | |
| 22 | 0607-524 | PLATE,BACKING-HOOD HINGE | 1 | $19.25 | |
| 23 | 0623-670 | SCREW,HDHS-1/4-20X1.125 Z&Y | 1 | $24.95 | |
| 24 | 0623-689 | SCREW,MACH-HSFH 10-24X1.25 Z&Y | 1 | $2.06 | |
| 25 | 8002-040 | SCREW,CAP-HH 1/4-20 X.75 G5 Z&Y | 1 | $0.40 | |
| 26 | 0616-998 | NOSEPIECE | 1 | $148.95 | |
| 27 | 8017-580 | SCREW,MACH-TSTRH 1/4-20 X 3/4 GR2 Z&Y | 1 | $2.06 | |
| 28 | 8002-041 | SCREW,CAP-HH 1/4-20 X.875 G5 Z&Y | 1 | $0.40 | |
| 29 | 8040-366 | NUT,HEX LOCK-NYL 1/4-20 Z&Y | 1 | $0.26 | |
| 30 | 8050-217 | WASHER,FLAT- 1/4 X .625 X .065 Z&Y | 1 | $0.12 |
