ELECTRIC START - STARTER MOTOR ASSEMBLY
2000 BEARCAT 440 II
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 0 | 1639-486 | KIT, ELEC START- 00 BRC 440 I/440 II | 1 | $733.95 | |
| 1 | 0645-329 | RING GEAR,ELECTRIC START-LW | 1 | $287.95 | |
| 2 | 0623-441 | R/B 1623-128 | 1 | $0.95 | |
| 4 | 8050-242 | WASHER,FLAT- 5/16 X .625 X .063 Z&Y | 1 | $2.06 | |
| 5 | 8040-426 | NUT,HEX LOCK-NYL 5/16-18 Z&Y | 1 | $0.40 | |
| 6 | 8002-135 | SCREW,CAP-HH 5/16-18 X1.50 G5 Z&Y | 1 | $0.65 | |
| 7 | 8051-247 | WASHER,SPR LOCK-5/16 .314X.593X.097 Z&Y | 1 | $0.40 | |
| 8 | 8050-247 | WASHER,FLAT- 5/16 X .688 X .065 Z&Y | 1 | $0.68 | |
| 9 | 0623-122 | NUT ,FLEX LOCK-THIN 1/4-20 | 1 | $1.50 | |
| 10 | 0645-115 | CABLE,SOLENOID-TO-STARTER [52"] | 1 | $66.95 | |
| 11 | 0623-144 | TIE,CABLE-17.5 LONG | 1 | $0.54 | |
| 12 | 0745-357 | R/B 0745-434 | 1 | $497.95 | |
| 13 | 0645-277 | CAP, COMMUTATOR-HD F/C ES | 1 | $177.95 | |
| 16 | 0645-189 | ARMATURE ASSY-EL START | 1 | $254.95 | |
| 17 | 0645-126 | WASHER,PINION-WAVE | 1 | $1.19 | |
| 18 | 0623-093 | BOLT, 5/16-18X1 1/2 RIBBED | 1 | $2.47 | |
| 19 | 0645-188 | CAP,DRIVE W/BEARING {56992-40CP} EL STAR | 1 | $117.95 | |
| 20 | 0645-191 | BOLT,STARTER MTR | 1 | $5.95 | |
| 21 | 0745-224 | KIT, DRIVE PINION-.63 | 1 | $106.95 | |
| 22 | 0645-186 | STOPPER KIT,PINION-EL START | 1 | $50.95 | |
| 23 | 0637-265 | UPDATE KIT,STARTER PINION DRIVE(4-1-2) | 1 | $92.95 | |
| 24 | 0645-127 | WASHER,THRUST-FLAT | 1 | $1.95 | |
| 25 | 0645-199 | STAND OFF,MTR MNT-EL START | 1 | $21.95 | |
| 26 | 0716-391 | CONDUIT, FLEXIBLE-.500 DIA 24" C/T/L | 1 | $3.99 |
