2001 Arctic Cat ZL 800 (ESR ILLUSION) — HOOD AND WINDSHIELD ASSEMBLY
2001 ZL 800 (ESR ILLUSION)
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0718-982 | HOOD, W/O DECALS | 1 | $1,131.95 | |
| 1 | 0718-931 | HOOD W/DECALS-01 ZL 800 ESR | 1 | $1,325.95 | |
| 1 | 0718-937 | HOOD-W/O DECALS | 1 | $1,229.95 | |
| 1 | 0718-987 | HOOD W/DECALS-SOLAR-01 ZL 800 ESR | 1 | $1,325.95 | |
| 3 | 0717-164 | FOAM, HOOD-UPR RH | 1 | $6.95 | |
| 3 | 0617-323 | FOAM,HOOD-UPPER LH | 1 | $53.95 | |
| 4 | 3611-820 | DECAL,HOOD-LOWER/RH | 1 | $63.95 | |
| 4 | 3611-821 | DECAL,HOOD-LOWER/LH | 1 | $63.95 | |
| 4 | 3611-925 | DECAL, HOOD, LWR, RH | 1 | $72.95 | |
| 4 | 3611-926 | DECAL, HOOD, LWR, LH | 1 | $70.95 | |
| 5 | 3611-822 | DECAL,HOOD-UPPER/RH | 1 | $86.95 | |
| 5 | 3611-823 | DECAL,HOOD-UPPER/LH | 1 | $86.95 | |
| 5 | 3611-927 | DECAL, HOOD, UPPER, RH | 1 | $71.95 | |
| 5 | 3611-928 | DECAL, HOOD, UPPER, LH | 1 | $72.95 | |
| 6 | 3611-485 | DECAL, WARNING-GENL & BRAKE-ENG & FRNCH | 1 | $35.95 | |
| 8 | 3611-970 | DECAL, CAUTION-ENG/BTRY/FUEL-ENG &FRCH | 1 | $41.95 | |
| 9 | 1606-067 | STRAP, HOLDDOWN- HOOD | 1 | $12.35 | |
| 11 | 3611-509 | DECAL, WARNING-SEATING CAPACITY | 1 | $72.95 | |
| 12 | 0123-010 | NUT,EXPANSION 10-32 | 1 | $6.75 | |
| 14 | 0623-690 | SCREW,HDHS-1/4-20X1.240 Z&Y | 1 | $24.77 | |
| 15 | 0623-797 | SCREW,SELF TAP-TSTH 10-12X1/2 WO/GP | 1 | $0.45 | |
| 16 | 1606-158 | CABLE HOOD 35.0" | 1 | $15.11 | |
| 17 | 2606-163 | WINDSHIELD, MED. (ZL) | 1 | $223.95 | |
| 18 | 0616-032 | O-RING-WINDSHIELD (1 I.D.) | 1 | $1.78 | |
| 19 | 0124-054 | SNAP CAP W/WASHER | 1 | $1.23 | |
| 20 | 0623-902 | SCREW, MACH-PHTRH-10-32X5/8-ZY | 1 | $0.95 | |
| 21 | 1606-938 | FOIL,HOOD-RH | 1 | $54.95 | |
| 21 | 1606-939 | FOIL, HOOD-LH | 1 | $75.95 | |
| 22 | 0623-845 | NUT, EXP,10-32 | 1 | $2.47 | |
| 23 | 0717-162 | FOAM, HOOD-REAR RH | 1 | $5.95 | |
| 23 | 0617-327 | FOAM,HOOD-REAR LH | 1 | $29.95 | |
| 24 | 1606-720 | HINGE, HOOD | 1 | $45.95 | |
| 25 | 3611-581 | DECAL, "ESR" | 1 | $23.95 | |
| 26 | 0617-328 | FOAM,HOOD-MIDDLE | 1 | $26.95 | |
| 27 | 3611-186 | DECAL, HOOD-"ARCTIC CAT"-GRN-CURVED | 1 | $21.95 | |
| 27 | 3611-835 | DECAL,HOOD (ARCTIC CAT-LIGHT DRIFT WOOD) | 1 | $29.95 | |
| 28 | 3611-580 | DECAL,REVERSE | 1 | $25.95 | |
| 29 | 0123-549 | SCREW,MACH-PHTRH 10-32 X 1.00 Z&Y | 1 | $0.29 | |
| 30 | 3611-834 | DECAL,HOOD-800 | 1 | $33.95 | |
| 30 | 3611-932 | DECAL, HOOD | 1 | $20.95 | |
| 31 | 2606-233 | FOIL, HOOD-UPR RH | 1 | $89.95 | |
| 32 | 4611-334 | DECAL,HOOD PAD-ACT-RH BLK | 1 | $8.95 | |
| 32 | 4611-335 | DECAL,HOOD PAD-ACT-LH BLK | 1 | $8.95 |
