REMOTE SHOCK LIMITER ASSEMBLY
2001 ZRT 800
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 0 | 0704-646 | ADJUSTER,FRT. ARM-EASY ADJUST,1.125 FLAT | 1 | $575.95 | |
| 1 | 0704-477 | ENDCAP,AJUSTER-ASSY | 1 | $200.95 | |
| 2 | 0704-478 | ENDCAP,KNOB-ASSY | 1 | $230.95 | |
| 3 | 0623-537 | PLUG,HOLE 1/2 DIA (DP 500) | 1 | $1.95 | |
| 4 | 1604-526 | KNOB, ADJUSTER,EASY ADJ. | 1 | $101.95 | |
| 5 | 8042-486 | NUT,3/8-16 HEX-REG-GR5 Z&Y | 1 | $0.26 | |
| 6 | 1604-271 | O-RING,OUTER | 1 | $2.47 | |
| 7 | 1604-273 | WASHER, BACKUP - .620 x .094 | 1 | $1.95 | |
| 8 | 1604-521 | DRIVE PIN, MACHINED, EASY ADJ. | 1 | $3.71 | |
| 9 | 1604-522 | STOP NUT, MACHINED, EASY ADJ. | 1 | $10.97 | |
| 10 | 0623-697 | SCREW, MACH - HSFH 10-24X3/8 BLK | 1 | $0.25 | |
| 11 | 2604-816 | PISTON,FLOATING-ASSY | 1 | $116.95 | |
| 12 | 1604-278 | STRAP, FLOATING PISTON - TEFLON | 1 | $24.77 | |
| 13 | 1604-277 | O-RING, FLOATING PISTON | 1 | $4.54 | |
| 14 | 1704-042 | KIT, ADJ BODY-REPLACEMENT | 1 | $142.95 | |
| 15 | 1604-535 | ENDCAP, RESERVOIR | 1 | $28.95 | |
| 16 | 1604-525 | CIRCLIP,RESERVOIR.063 DIA.X 1.42 ID | 1 | $6.95 | |
| 17 | 1604-531 | HOSE, ADJUSTER TO Q D COUPLER, 38IN. | 1 | $102.95 | |
| 18 | 1604-537 | HYDRAULIC COUPLING NIPPLE, FEMALE THREAD | 1 | $97.95 | |
| 19 | 3611-691 | DECAL,SHOCK-"ACT" | 1 | $23.95 | |
| 20 | 4639-366 | S/M SHOCK OIL-1 QUART | 1 | $21.95 | |
| 21 | 0423-182 | O-RING,-008 (3/16X5/16X1/16) | 1 | $1.23 |
