EXHAUST ASSEMBLY
2002 MOUNTAIN CAT 800
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0712-424 | CHAMBER,EXP FAB- 785 | 1 | $417.95 | |
| 2 | 0712-387 | CHAMBER,EXP (785)-PTD BLK | 1 | $873.95 | |
| 3 | 1612-254 | COVER ,EXP CHAMBER UPPER | 1 | $137.95 | |
| 4 | 1612-255 | COVER,EXP CHAMBER LOWER | 1 | $167.95 | |
| 5 | 1612-256 | WRAP, EXH,EXP CHAMBER UPPER | 1 | $34.95 | |
| 6 | 1612-257 | WRAP, EXH,EXP CHAMBER LOWER | 1 | $40.95 | |
| 7 | 1612-178 | SPRING, EXHAUST STRAP | 1 | $3.85 | |
| 8 | 0624-552 | TIE, PERFORATED BAND-5FT | 1 | $20.63 | |
| 8 | 0624-541 | TIE,PERFORATED BAND-IT( 25' ) | 1 | $110.95 | |
| 9 | 0612-027 | SPRING EXTENSION | 1 | $27.95 | |
| 10 | 0612-471 | SPRING,EXHAUST | 1 | $12.35 | |
| 11 | 2612-399 | SPRING,EXTENSION | 1 | $3.71 | |
| 12 | 0712-386 | MANIFOLD,EXHAUST-PTD | 1 | $599.95 | |
| 13 | 1612-014 | GASKET,EXHAUST HEADPIPE | 1 | $37.95 | |
| 14 | 0612-993 | GASKET,EXHAUST - TAIL PIPE (99-700) | 1 | $29.95 | |
| 15 | 0712-746 | RESONATOR-PTD BLK | 1 | $549.95 | |
| 16 | 0712-691 | BRKT,MTG EXP CHAMBER-PTD BLK | 1 | $44.95 | |
| 17 | 0612-107 | BUSHING,RESONATOR MTG | 1 | $12.95 | |
| 18 | 0623-856 | SCREW, HEX HEAD SHOULDER-1/4-20 | 1 | $5.95 | |
| 19 | 8040-366 | NUT,HEX LOCK-NYL 1/4-20 Z&Y | 1 | $0.26 | |
| 20 | 0623-961 | NUT, HEX 5/16-18 W/WASHER | 1 | $0.26 | |
| 21 | 1612-321 | SUPPORT, RESONATOR-RUBBER | 1 | $22.01 | |
| 22 | 1612-340 | BRKT,MTG,(RESONATOR-DROPCASE) | 1 | $45.95 | |
| 23 | 8002-134 | SCREW,CAP-HH 5/16-18 X1.25 G5 Z&Y | 1 | $0.65 | |
| 24 | 8053-242 | WASHER,LOCK-5/16 EXT TOOTH TYP A Z&Y | 1 | $0.12 | |
| 25 | 8002-040 | SCREW,CAP-HH 1/4-20 X.75 G5 Z&Y | 1 | $0.40 | |
| 26 | 8051-217 | WASHER,SPR LOCK-1/4 .252X.489X.077 Z&Y | 1 | $0.35 | |
| 27 | 0686-126 | HARNESS,ENGINE-GROUND | 1 | $12.35 | |
| 28 | 1612-319 | BUSHING, STEM RESONATOR MTG | 1 | $3.95 | |
| 29 | 0712-705 | BRKT, MTG-RESONATOR-PTD BLK | 1 | $36.95 | |
| 30 | 0712-916 | BRKT,MTG-RESONATOR/CHASSIS-PTD BLK | 1 | $5.95 | |
| 31 | 8050-242 | WASHER,FLAT- 5/16 X .625 X .063 Z&Y | 1 | $2.06 |
