PISTON AND CRANKSHAFT
2002 PANTERA 550 ()
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 2 | 3003-760 | RING SET,550L/C | 1 | $125.95 | |
| 3 | 3003-767 | PIN,PISTON | 1 | $38.95 | |
| 4 | 3003-433 | BEARING,PISTON PIN,ROLLER,M20X26X24 | 1 | $42.95 | |
| 5 | 3003-439 | CIRCLIP,PISTON PIN,M20 | 1 | $3.16 | |
| 6 | 3005-209 | WASHER,20MM | 1 | $13.73 | |
| 7 | 3005-752 | CRANKSHAFT ASSY ( 550 L/C ) | 1 | $2,849.95 | |
| 8 | 3005-112 | ROD, CONNECTING | 1 | $283.95 | |
| 9 | 3003-784 | BEARING,NEEDLE ROLLER,26X32X19.8 | 1 | $113.95 | |
| 10 | 3003-812 | CRANKSHAFT,RH | 1 | $486.95 | |
| 11 | 3005-753 | CRANKSHAFT, MIDDLE | 1 | $438.95 | |
| 12 | 3005-232 | WHEEL, CRANKSHAFT | 1 | $543.95 | |
| 13 | 3005-231 | CRANKSHAFT, LH | 1 | $417.95 | |
| 14 | 3003-815 | BALANCER, CRANKSHAFT | 1 | $35.95 | |
| 15 | 3007-440 | SCREW | 1 | $2.06 | |
| 16 | 3004-698 | RACE,MIDDLE SEAL | 1 | $82.95 | |
| 17 | 3003-817 | RING,MID CRANK SEAL | 1 | $32.95 | |
| 18 | 3005-202 | GEAR, OIL PUMP DRIVE | 1 | $201.95 | |
| 19 | 3005-210 | BEARING,BALL,M30 | 1 | $101.95 | |
| 20 | 3003-164 | BEARING, CRANKSHAFT,BALL,M30X72X16 | 1 | $108.95 | |
| 21 | 3003-782 | WASHER,M26 X 31 X 1.5 | 1 | $5.09 | |
| 22 | 3003-805 | BEARING,CRANK-LH,ROLLER,M40X64X30 | 1 | $244.95 | |
| 23 | 3004-540 | KEY,WOODRUFF,M4 | 1 | $6.34 | |
| 24 | 3003-783 | WASHER,M26 X 31 X 2.0 | 1 | $9.59 | |
| 25 | 3003-933 | WASHER,CRANK PIN | 1 | $14.95 | |
| 26 | 3005-188 | SEAL,CRANKSHAFT-RH,M30 | 1 | $77.95 | |
| 27 | 3003-759 | R/B 0930-051 | 1 | $54.95 | |
| 28 | 3003-216 | C-RING, CRANKSHAFT,M72 | 1 | $6.06 | |
| 29 | 3003-658 | PIN,ALIGNMENT | 1 | $3.16 | |
| 30 | 3005-324 | GEAR, DRIVEN | 1 | $187.95 | |
| 31 | 3005-049 | SHIM,10MM | 1 | $3.57 | |
| 32 | 3005-909 | SEAL, MECHANICAL WATER PUMP | 1 | $66.95 | |
| 33 | 3007-431 | OIL SEAL-10X22X6 | 1 | $16.49 | |
| 34 | 3006-685 | PISTON ASSY. 04' 550 L/C | 1 | $251.95 |
