HOOD AND WINDSHIELD ASSEMBLY (CC International)

2002 ZR 500 CC ()

Scroll / pinch to zoom · drag to pan · double-click resets

#	Part No.	Description	Qty	Price
1	1718-107	HOOD W/DECALS-LE GRN-02 ZR 500	1	$1,264.95
2	1718-032	HOOD,W/O DECAL-ZR 500	1	$1,168.95
4	0617-322	FOAM,HOOD-UPPER RH	1	$42.95
4	0617-323	FOAM,HOOD-UPPER LH	1	$53.95
5	0617-326	FOAM,HOOD-REAR RH	1	$17.95
5	0617-327	FOAM,HOOD-REAR LH	1	$29.95
6	0617-328	FOAM,HOOD-MIDDLE	1	$26.95
7	3611-485	DECAL, WARNING-GENL & BRAKE-ENG & FRNCH	1	$35.95
8	3611-970	DECAL, CAUTION-ENG/BTRY/FUEL-ENG &FRCH	1	$41.95
9	3611-509	DECAL, WARNING-SEATING CAPACITY	1	$72.95
10	4611-334	DECAL,HOOD PAD-ACT-RH BLK	1	$8.95
10	4611-335	DECAL,HOOD PAD-ACT-LH BLK	1	$8.95
11	1606-938	FOIL,HOOD-RH	1	$54.95
11	1606-939	FOIL, HOOD-LH	1	$75.95
12	1606-720	HINGE, HOOD	1	$45.95
13	0623-797	SCREW,SELF TAP-TSTH 10-12X1/2 WO/GP	1	$0.45
14	4611-466	DECAL, HOOD-GRN-CTR	1	$41.95
15	4611-472	DECAL, HOOD-500-RH-GRN	1	$89.95
15	4611-471	DECAL, HOOD-500-LH-GRN	1	$100.95
16	4611-452	DECAL, HOOD-LWR RH-GRN	1	$16.95
16	4611-453	DECAL, HOOD-LWR-LH-GRN	1	$251.95
17	4611-462	DECAL, HOOD-VENT-RR RH-GRN	1	$66.95
17	4611-463	DECAL, HOOD-VENT-RR LH-GRN	1	$35.95
18	4611-464	DECAL, HOOD-VENT-FRT RH-GRN	1	$99.95
18	4611-465	DECAL, HOOD-VENT-FRT LH-GRN	1	$99.95
19	3611-187	DECAL, HOOD-"ARCTIC CAT"-BLK	1	$26.95
20	1606-158	CABLE HOOD 35.0"	1	$15.11
22	1606-067	STRAP, HOLDDOWN- HOOD	1	$12.35
23	0623-690	SCREW,HDHS-1/4-20X1.240 Z&Y	1	$24.77
26	0616-032	O-RING-WINDSHIELD (1 I.D.)	1	$1.78
27	0124-054	SNAP CAP W/WASHER	1	$1.23
28	0623-902	SCREW, MACH-PHTRH-10-32X5/8-ZY	1	$0.95
29	0623-845	NUT, EXP,10-32	1	$2.47
