2003 Arctic Cat 4-STROKE TOURING () — TIMING CHAIN COVER/OIL PUMP ASSEMBLY
2003 4-STROKE TOURING ()
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3006-219 | PUMP ASSY,OIL '02 660 L/C | 1 | $964.95 | |
| 2 | 3006-220 | ROTOR SET,OIL PUMP '02 660 L/C | 1 | $314.95 | |
| 3 | 3007-393 | SCREW,M6X16 | 1 | $2.06 | |
| 4 | 3006-221 | VALVE SET,OIL PUMP RELIEF '02 660 L/C | 1 | $43.95 | |
| 6 | 3006-592 | FILTER OIL GALLERY | 1 | $24.77 | |
| 7 | 3006-102 | BOLT,8X40 '02 660 L/C | 1 | $5.95 | |
| 8 | 3423-386 | PLUG, RH | 1 | $10.97 | |
| 9 | 3007-395 | BOLT | 1 | $3.44 | |
| 10 | 3007-386 | BOLT | 1 | $3.16 | |
| 11 | 3007-396 | BOLT, CYLINDER HEAD-M8X40 | 1 | $4.68 | |
| 12 | 3005-206 | PIN (H:10),DOWEL | 1 | $3.30 | |
| 13 | 3007-036 | SWITCH ASSY,OIL PRESSURE | 1 | $56.95 |
