2003 Arctic Cat FIRECAT 700 EFI — BELLY PAN AND SEAT ASSEMBLIES
2003 FIRECAT 700 EFI
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 7996-954 | SEAT-MFG ASSY(TA 500/700 GRN) | 1 | $1,070.95 | |
| 1 | 7996-955 | SEAT-MFG ASSY(TA 500/700 BLK) | 1 | $800.95 | |
| 1 | 7996-956 | SEAT-MFG ASSY(TA 500/700 RED) | 1 | $769.95 | |
| 2 | 2706-080 | COVER,SEAT-W/DECALS(TA 500/700 GRN) | 1 | $414.95 | |
| 2 | 2706-081 | R/B 6706-403 | 1 | $510.95 | |
| 2 | 2706-082 | COVER,SEAT-W/DECALS(TA 500/700 RED) | 1 | $594.95 | |
| 3 | 4611-996 | DECAL,BELLY PAN-RH GRN "F7" | 1 | $200.95 | |
| 3 | 4611-997 | DECAL,BELLY PAN-LH GRN "F7" | 1 | $59.95 | |
| 3 | 5611-008 | DECAL,BELLY PAN-RH BLK "F7" | 1 | $69.95 | |
| 3 | 5611-009 | DECAL,BELLY PAN-LH BLK "F7" | 1 | $66.95 | |
| 3 | 5611-016 | DECAL,BELLY PAN-RH RED "F7" | 1 | $64.95 | |
| 3 | 5611-017 | DECAL,BELLY PAN-LH RED "F7" | 1 | $64.95 | |
| 4 | 5611-116 | DECAL,BELLY PAN-LWR GRN RH | 1 | $59.95 | |
| 4 | 5611-117 | DECAL,BELLY PAN-LWR GRN LH | 1 | $72.95 | |
| 4 | 5611-118 | DECAL,BELLY PAN-LWR BLK RH | 1 | $69.95 | |
| 4 | 5611-119 | DECAL,BELLY PAN-LWR BLK LH | 1 | $66.95 | |
| 4 | 5611-120 | DECAL,BELLY PAN-LWR RED RH | 1 | $64.95 | |
| 4 | 5611-121 | DECAL,BELLY PAN-LWR RED LH | 1 | $64.95 |
