2003 Arctic Cat Z 440 SNO PRO — HOOD AND WINDSHIELD ASSEMBLY
2003 Z 440 SNO PRO
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 1718-347 | HOOD,W/DECALS | 1 | $1,374.95 | |
| 2 | 1718-012 | HOOD, W/O,DECAL | 1 | $1,229.95 | |
| 3 | 0717-148 | FOAM, HOOD-MIDDLE UPR RH | 1 | $15.11 | |
| 3 | 0717-149 | FOAM, HOOD-MIDDLE UPR LH | 1 | $14.95 | |
| 4 | 0717-146 | FOAM, HOOD-UPR RH | 1 | $14.95 | |
| 5 | 0717-138 | FOAM, HOOD-MIDDLE-00 ZR | 1 | $5.95 | |
| 6 | 0717-156 | FOAM,HOOD-REAR RH | 1 | $8.95 | |
| 7 | 3611-485 | DECAL, WARNING-GENL & BRAKE-ENG & FRNCH | 1 | $35.95 | |
| 8 | 3611-970 | DECAL, CAUTION-ENG/BTRY/FUEL-ENG &FRCH | 1 | $41.95 | |
| 9 | 3611-509 | DECAL, WARNING-SEATING CAPACITY | 1 | $72.95 | |
| 10 | 1606-938 | FOIL,HOOD-RH | 1 | $54.95 | |
| 10 | 1606-939 | FOIL, HOOD-LH | 1 | $75.95 | |
| 11 | 1606-720 | HINGE, HOOD | 1 | $45.95 | |
| 12 | 0623-797 | SCREW,SELF TAP-TSTH 10-12X1/2 WO/GP | 1 | $0.45 | |
| 13 | 5611-134 | DECAL,HOOD-VENT REAR RH | 1 | $18.95 | |
| 13 | 5611-135 | DECAL,HOOD-VENT REAR LH | 1 | $18.95 | |
| 14 | 5611-132 | DECAL,HOOD-VENT CENTER-RH | 1 | $20.63 | |
| 14 | 5611-133 | DECAL,HOOD-VENT CENTER-LH | 1 | $19.25 | |
| 15 | 5611-128 | DECAL,HOOD-LOWER RH "F/C" | 1 | $105.95 | |
| 15 | 5611-129 | DECAL,HOOD-LOWER LH "F/C" | 1 | $105.95 | |
| 16 | 5611-125 | DECAL,HOOD-CREST | 1 | $39.95 | |
| 17 | 3611-187 | DECAL, HOOD-"ARCTIC CAT"-BLK | 1 | $26.95 | |
| 18 | 5611-130 | DECAL,HOOD-VENT FORWARD-RH | 1 | $26.95 | |
| 18 | 5611-131 | DECAL,HOOD-VENT FORWARD-LH | 1 | $26.95 | |
| 19 | 0124-054 | SNAP CAP W/WASHER | 1 | $1.23 | |
| 20 | 0623-902 | SCREW, MACH-PHTRH-10-32X5/8-ZY | 1 | $0.95 | |
| 21 | 2606-901 | WINDSHIELD,GRN CHROME-W/GRAPHICS | 1 | $317.95 | |
| 22 | 0623-845 | NUT, EXP,10-32 | 1 | $2.47 | |
| 23 | 0616-032 | O-RING-WINDSHIELD (1 I.D.) | 1 | $1.78 | |
| 24 | 1606-067 | STRAP, HOLDDOWN- HOOD | 1 | $12.35 | |
| 25 | 1606-870 | DUCT,AIR OUT(2000 Z PRO) | 1 | $61.95 | |
| 26 | 5611-123 | DECAL,JET CHART-2003 Z 440 SNO PRO | 1 | $35.95 | |
| 27 | 0123-802 | WASHER,FLAT .194X.50X.048-Z&Y | 1 | $0.12 | |
| 28 | 8060-508 | RIVET,BLIND-DH SS56 BLK | 1 | $0.26 | |
| 29 | 2606-069 | PLUG, GAUGE HOLE | 1 | $5.37 | |
| 30 | 1606-441 | HOLDDOWN,HOOD STRAP-SIDE ('98 440 PRO) | 1 | $13.73 | |
| 30 | 2606-096 | HOLDDOWN,HOOD STRAP-SIDE RH | 1 | $30.95 | |
| 31 | 8061-708 | RIVET, BLIND-LF SS66 BLACK | 1 | $0.95 | |
| 32 | 0623-690 | SCREW,HDHS-1/4-20X1.240 Z&Y | 1 | $24.77 | |
| 33 | 2706-051 | DUCT,AIR-ASSY | 1 | $58.95 | |
| 34 | 0619-206 | TAPE,ALUM FOIL - 6" X 30 FT | 1 | $7.77 | |
| 35 | 0623-165 | CLIP, X-MAS TREE-5/32 | 1 | $1.50 | |
| 36 | 2606-441 | PAD, AIR-IN DUCT- '01 440 Z PRO | 1 | $47.95 | |
| 39 | 1606-158 | CABLE HOOD 35.0" | 1 | $15.11 | |
| 40 | 0623-257 | SCREW,SELF TAP-HWH #8X1/2 TYPE A | 1 | $1.09 |
