2004 Arctic Cat ARCTIC CAT 440 SNO PRO — ENGINE AND RELATED PARTS
2004 ARCTIC CAT 440 SNO PRO
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0662-371 | ENGINE,440 L/C-ZRVB-04 | 1 | $3,786.95 | |
| 2 | 0636-363 | HANDLE,RECOIL-LARGE | 1 | $15.11 | |
| 3 | 0606-885 | CAP,RECOIL HANDLE | 1 | $1.37 | |
| 4 | 0608-420 | BRKT,ENG MTG-RH | 1 | $45.95 | |
| 5 | 8002-136 | SCREW,CAP-HH 5/16-18 X1.75 G5 Z&Y | 1 | $0.95 | |
| 6 | 8408-830 | SCREW,CAP-HFH M8X1.25X30 CL8.8 Z&Y | 1 | $0.95 | |
| 7 | 8047-426 | NUT,HEX FLG-NY LOCK 5/16-18 GR F Z&Y | 1 | $0.68 | |
| 8 | 1670-328 | FOIL, PROTECTIVE-RECOIL COVER-DIE CUT | 1 | $16.49 | |
| 9 | 0670-243 | PLUG, GAS TANK-1/4 NPT | 1 | $1.92 | |
| 10 | 0670-289 | TAPE, TEFLON-ROLL | 1 | $6.34 | |
| 11 | 0623-801 | ADAPTER,FITTING-1/4-18 NPTF X 1/4 FHB | 1 | $13.73 | |
| 12 | 0124-045 | CLAMP,HOSE - .402/.449 DIA (SNP04) | 1 | $2.61 | |
| 13 | 0610-007 | HOSE, IMPULSE 3/16 25' | 1 | $102.95 | |
| 14 | 0608-401 | SNUBBER,BOTTOM OUT | 1 | $38.95 | |
| 15 | 1623-031 | R/B 2623-165 | 1 | $3.95 | |
| 16 | 0708-435 | BRKT,ENG MTG-LH ASSY | 1 | $226.95 | |
| 17 | 8048-426 | NUT,HEX FLG-TOP LOCK 5/16-18 GR F Z&Y | 1 | $1.23 | |
| 18 | 0608-418 | REINFORCEMENT-MOTOR MOUNT | 1 | $15.11 | |
| 19 | 0623-765 | SCREW,SELF TAP-HWH 5/16-18X.625 TT Z&Y | 1 | $1.23 | |
| 20 | 8408-825 | SCREW,CAP-HFH M8X1.25X25 CL8.8 Z&Y | 1 | $1.23 | |
| 21 | 0746-422 | CLUTCH,DRIVE-UNCAL-8.0" 30MM/D/NFP/440SP | 1 | $971.95 | |
| 22 | 0627-010 | BELT, DRIVE CVT-12.2 | 1 | $106.95 | |
| 23 | 0623-210 | WASHER, LOCK-1/2" HI-COLLAR | 1 | $0.68 | |
| 24 | 0623-804 | BOLT, CLUTCH-1/2-20X5-1/5-12 PT | 1 | $15.11 | |
| 25 | 0123-811 | TIE,CABLE-4 INCH PLT1M | 1 | $0.26 | |
| 26 | 0123-788 | TIE,CABLE-8.5/7.5/7.4 | 1 | $0.12 |
