2004 Arctic Cat FIRECAT 600 EFI SNO PRO 1 LIMITED EDITION — BELLY PAN, SEAT, TUNNEL, AND SNOWFLAP TIGER RED
2004 FIRECAT 600 EFI SNO PRO 1 LIMITED EDITION
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 2 | 2706-489 | COVER,SEAT-RED W/GRAPHIC | 1 | $466.95 | |
| 3 | 5611-834 | DECAL,TUNNEL-RED RH | 1 | $60.95 | |
| 3 | 5611-835 | DECAL,TUNNEL-RED LH | 1 | $60.95 | |
| 5 | 2706-226 | BELLY PAN,SNO PRO RED-RH ROUTED | 1 | $251.95 | |
| 5 | 2706-227 | BELLY PAN,SNO PRO RED-LH ROUTED | 1 | $263.95 | |
| 6 | 5611-832 | DECAL,BELLY PAN-RED RH | 1 | $64.95 | |
| 6 | 5611-833 | DECAL,BELLY PAN-RED LH | 1 | $64.95 | |
| 7 | 2606-775 | PANEL, CLUTCH ACCESS-RED | 1 | $17.95 |
