DROPCASE CHAIN TENSION ASSEMBLY
2004 KING CAT 900
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0623-526 | SCREW,SELF TAP-TSPNH 10-32X.375 TR Z&Y | 1 | $5.65 | |
| 2 | 0602-645 | COVER,ADJUSTOR HSG | 1 | $88.95 | |
| 3 | 0602-803 | SPRING,POWER-ADJUSTER SHAFT | 1 | $94.95 | |
| 4 | 1602-536 | SHAFT, CHAIN ADJUSTOR | 1 | $21.95 | |
| 5 | 0602-748 | SCREW, CHAIN ADJUSTER | 1 | $53.95 | |
| 6 | 0602-901 | SPRING, COMPRESSION-ADJ SCREW | 1 | $26.95 | |
| 7 | 0602-804 | RIVET,BTNHD 3/16 X 3/4 | 1 | $0.26 | |
| 8 | 0602-801 | O-RING-COVER-CHAIN ADJUSTER (2-031) | 1 | $1.09 | |
| 10 | 0623-541 | SCREW, MACH-HH 10-32 X .25 | 1 | $0.68 | |
| 11 | 0602-675 | ARM, CHAIN ROLLER | 1 | $35.95 | |
| 12 | 8002-045 | SCREW, CAP-HH 1/4-20 X 1.50 G5 Z&Y | 1 | $0.95 | |
| 13 | 0623-122 | NUT ,FLEX LOCK-THIN 1/4-20 | 1 | $1.50 | |
| 14 | 0602-681 | NUT, ROLLER ARM | 1 | $82.95 | |
| 15 | 8050-222 | WASHER,FLAT- 1/4 X .734 X .063 Z&Y | 1 | $0.68 | |
| 16 | 0623-525 | WASHER, FLAT-.5 X 1.01 OD HARDENED | 1 | $7.72 | |
| 17 | 0702-129 | ROLLER ASSY-CHAIN TIGHTENER | 1 | $60.95 | |
| 18 | 0602-383 | BEARING,CHAIN TIGHTENER-1/2 ID X .75 | 1 | $3.95 | |
| 19 | 0602-676 | SHAFT, CHAIN ROLLER | 1 | $20.95 |
