OIL TANK ASSEMBLY
2006 M7 EFI 162 CT
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 1670-930 | TANK,OIL-CLEAR | 1 | $131.95 | |
| 2 | 1670-325 | GROMMET, 1/4"-FUEL TANK | 1 | $2.88 | |
| 3 | 1670-481 | FITTING,OIL TANK | 1 | $4.26 | |
| 4 | 0609-503 | SENSOR,OIL LEVEL-ROTARY W/SEAL | 1 | $75.95 | |
| 5 | 0609-518 | SWITCH, OIL-W/HARNESS- ASSY | 1 | $102.95 | |
| 6 | 0609-237 | SEAL,GROMMET-OIL SENSOR (REF 0609-224) | 1 | $3.44 | |
| 7 | 1670-365 | CAP, VENTED- OIL IMPRINTED | 1 | $33.95 | |
| 8 | 0109-733 | SEAL,GAS CAP | 1 | $3.57 | |
| 9 | 4611-532 | DECAL,OIL TANK-VEV SYNTHETIC | 1 | $2.75 | |
| 10 | 0124-045 | CLAMP,HOSE - .402/.449 DIA (SNP04) | 1 | $2.61 | |
| 11 | 0610-015 | HOSE,GAS 1/4 X100' | 1 | $231.59 | |
| 11 | 0610-016 | HOSE,GAS 1/4 X25' | 1 | $117.95 | |
| 12 | 1623-256 | GROMMET,RUBBER-.63"ID X 1.13"OD X .19"GR | 1 | $3.99 | |
| 13 | 3606-982 | SHIELD,HEAT-OIL TANK | 1 | $22.01 | |
| 14 | 8050-157 | WASHER,FLAT- #10 X .500 X .049 Z&Y | 1 | $1.23 | |
| 15 | 8017-395 | SCREW,MACH-TSTRH 10-24X.375 GR2 Z&Y | 1 | $1.95 | |
| 16 | 8017-577 | SCREW,MACH-TSTRH 1/4-20 X 1/2 GR2 Z&Y | 1 | $1.23 | |
| 17 | 0123-811 | TIE,CABLE-4 INCH PLT1M | 1 | $0.26 |
