2008 Arctic Cat AC 600 SNO PRO — AIR SILENCER, CARBURETOR, AND FUEL PUMP ASSEMBLY
2008 AC 600 SNO PRO
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 5606-633 | SCREEN,AIR SILENCER | 1 | $156.95 | |
| 2 | 5606-244 | R/B 6606-266 | 1 | $362.95 | |
| 3 | 6990-283 | VELCRO,HOOK-SELF LOCK W/ADH-1"X80" | 1 | $78.95 | |
| 4 | 0423-577 | CLIP,U-NUT M6 | 1 | $0.40 | |
| 5 | 0423-130 | SCREW,FUEL TANK | 1 | $5.65 | |
| 6 | 5606-632 | SCREEN,INTAKE | 1 | $75.95 | |
| 7 | 5606-247 | R/B 5606-836 | 1 | $144.95 | |
| 8 | 2606-554 | FOIL,PROTECTIVE-3" X 4" | 1 | $3.44 | |
| 9 | 1670-984 | BOOT,CARB | 1 | $99.95 | |
| 10 | 1670-977 | CARB,TM40-B388 | 1 | $1,216.95 | |
| 11 | 0623-652 | CLAMP,HOSE-WIRE(CP10101) | 1 | $1.78 | |
| 12 | 0610-442 | HOSE, DRAIN (1.5") | 1 | $4.40 | |
| 13 | 1623-197 | CLAMP, HOSE-SPRING-14MM | 1 | $2.75 | |
| 14 | 0410-143 | HOSE,FUEL-1/4" 25' (0410-141 CTL) | 1 | $217.95 | |
| 15 | 0123-788 | TIE,CABLE-8.5/7.5/7.4 | 1 | $0.12 | |
| 16 | 8427-602 | NUT,HEX FLG-NYL LOCK M6X1.0 CL8 Z&Y | 1 | $0.12 | |
| 17 | 1670-230 | PUMP,FUEL W/O OIL INLET | 1 | $75.95 | |
| 18 | 1623-777 | CLAMP,CABLE | 1 | $3.85 | |
| 19 | 8408-625 | SCREW,CAP-HFH M6X1.0X25 CL8.8 Z&Y | 1 | $0.54 |
