2008 Arctic Cat BEARCAT 570 LONG TRACK — FRONT SUSPENSION SHOCK ABSORBER ASSEMBLY
2008 BEARCAT 570 LONG TRACK
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 1603-889 | RETAINER, SPRING | 1 | $12.35 | |
| 2 | 2703-228 | SPRING, COMPRESSION-PTD RED METALLIC | 1 | $77.95 | |
| 3 | 0603-259 | NUT,RETAINER-SPRING | 1 | $5.65 | |
| 4 | 0603-147 | SLEEVE,THREADED-SHOCK | 1 | $60.95 | |
| 5 | 1603-253 | SHOCK ABSORBER - SKI | 1 | $167.95 | |
| 6 | 0604-310 | BUSHING,SHOCK ABSORBER | 1 | $6.75 | |
| 7 | 8047-486 | NUT,HEX FLG-NY LOCK 3/8-16 GR F Z&Y | 1 | $0.95 | |
| 8 | 8020-226 | SCREW,CAP-HFH 3/8-16 X 1.75 Z&Y | 1 | $2.95 | |
| 9 | 1604-184 | SLEEVE, SHOCK ABSORBER | 1 | $42.95 | |
| 10 | 0603-855 | SPACER, SHOCK MTG - REAR | 1 | $3.99 | |
| 11 | 0603-854 | SPACER, SHOCK MTG - FRT | 1 | $13.73 | |
| 12 | 8020-234 | SCREW,CAP-HFH 3/8-16 X 4.00 Z&Y | 1 | $6.89 |
