2008 Arctic Cat CROSSFIRE 1000 EFI SNO PRO LIMITED EDITION — DRIVE CLUTCH
2008 CROSSFIRE 1000 EFI SNO PRO LIMITED EDITION
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0746-841 | KIT,DRIVE CLUTCH | 1 | $850.95 | |
| 2 | 1623-670 | SCREW,CAP FH SHOULDER 1/4-20X2.5 GD 8 | 1 | $20.63 | |
| 3 | 8051-242 | WASHER,SPR LOCK-5/16 .314X.583X.078 Z&Y | 1 | $1.64 | |
| 4 | 4639-674 | KIT,CAM ARM REPAIR '05-'09(WIDE) | 1 | $58.95 | |
| 5 | 8048-366 | NUT,HEX FLG-TOP LOCK 1/4-20 GR F Z&Y | 1 | $0.68 | |
| 6 | 1602-692 | O-RING, 5/16 X 1/2 X 3/32 - VITON | 1 | $0.68 | |
| 7 | 1623-183 | SCREW,SET-CUP PT W/THD LOC-8-32X3/16 | 1 | $1.64 | |
| 8 | 0646-747 | PIN, CAM ARM | 1 | $17.87 | |
| 9 | 0746-773 | ARM,CAM-WIDE-P1-85 GRAM-W/SET SCREW | 1 | $23.39 | |
| 9 | 0746-814 | ARM,CAM-P1 (FLN2)-83 GRAM-W/SET SCREW | 1 | $13.73 | |
| 9 | 0746-673 | ARM,CAM-WIDE-P1-80 GRAM W/SET SCREW | 1 | $13.73 | |
| 9 | 0746-672 | ARM,CAM-WIDE-P1-75 GRAM W/SET SCREW | 1 | $13.73 | |
| 10 | 0646-155 | SPRING,CLUTCH-PURP | 1 | $88.95 | |
| 10 | 0646-229 | SPRING,CLUTCH-YELLOW/WHITE | 1 | $54.95 |
