REED VALVE ASSEMBLY
2008 M1000 EFI 153 SNO PRO
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3007-282 | VALVE ASSY,REED | 1 | $231.95 | |
| 2 | 3007-283 | STOPPER,REED VALVE | 1 | $29.95 | |
| 3 | 3007-048 | VALVE,REED | 1 | $34.95 | |
| 4 | 3004-506 | SCREW, 3X8 | 1 | $2.47 | |
| 5 | 3005-879 | GASKET, REED VALVE | 1 | $17.87 | |
| 6 | 3007-284 | PIPE,INTAKE | 1 | $169.95 | |
| 7 | 3007-719 | CLAMP,INTAKE PIPE | 1 | $15.11 | |
| 8 | 3007-380 | BOLT | 1 | $3.16 |
