2009 Arctic Cat Z1 TURBO LXR LE — CRANK BALANCER ASSEMBLY
2009 Z1 TURBO LXR LE
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3007-133 | BALANCER,CRANK NO. 1 | 1 | $730.95 | |
| 2 | 3007-134 | BALANCER,CRANK NO. 2 | 1 | $730.95 | |
| 3 | 3007-135 | BEARING,CRANK BALANCER | 1 | $20.63 | |
| 3 | 3007-136 | BEARING,CRANK BALANCER | 1 | $20.63 | |
| 3 | 3007-137 | BEARING,CRANK BALANCER | 1 | $20.63 | |
| 4 | 3007-138 | PLUG,CRANK BALANCER | 1 | $22.01 |
